Wellbore #00 Wellbore Classification: OW Status: SI - 10/1/2023 Measured TD: 11383 ft. Vertical TD: 6967 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW SI - 10/1/2023 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 5/15/2015 | | Proposed Top PZ Location: | Sec:33 Twp: 7N 65W | Footage: 1726 FNL 816 FEL | | Bottom Hole Location: | Sec:33 Twp: 7N 65W | Footage: 1743 FNL 500 FWL | | Proposed Depth/Form: | 11439 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 320, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 875 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 830, Top: 0 ft., Bottom: 875 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7498 ft., Weight: 26 , Citings Type: PLANNED | | Cement: | Sacks: 650, Top: 500 ft., Bottom: 7498 ft. | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6296 ft., Depth: 11439 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 4/15/2015 | | Spud Date: | 4/8/2015 | Spud Date Is: | ACTUAL | | Measured TD: | 11383 ft. | Measured PB depth: | 11376 ft. | | True Vertical TD: | 6967 ft. | True Vertical PB depth: | 6967 ft. | | Top PZ Location: | Sec:33 Twp: 7N 65W | Footage: 1721 FNL 944 FEL | | Bottom Hole Location: | Sec:33 Twp: 7N 65W | Footage: 1746 FNL 500 FWL | | Log Types: | CBL, MWD (DIL in 123-23733) | | Casing: | String Type: SURF, Hole Size: 13.75 in., Size: 9.625 in., Top: 0 ft., Depth: 927 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 760, Top: 0 ft., Bottom: 927 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7494 ft., Weight: 26 , Citings Type: ACTUAL | | Cement: | Sacks: 770, Top: 100 ft., Bottom: 7494 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 7053 ft., Depth: 11379 ft., Weight: 13.5 , Citings Type: ACTUAL | | Cement: | Sacks: , Top: , Bottom: , Determination Method: | | Formation | Interval Top | Log Bottom | Cored | DSTs | | PARKMAN | 3774 ft. | | | | | SUSSEX | 4534 ft. | | | | | SHANNON | 5224 ft. | | | | | SHARON SPRINGS | 6686 ft. | | | | | NIOBRARA | 6918 ft. | | | |
Formation NBRR Formation Classification: OW Status: SI - 10/1/2023 Interval Top: 7550 ft. Interval Bottom: 11383 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 7/6/2015 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | Yes |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 6/20/2015 | Treatment End Date: | 6/21/2015 | | Treatment Summary: | 20 Stage Sliding Sleeve
Total Fluid: 78,391 bbls
Gel Fluid: 60,693 bbls
Slickwater Fluid: 17,698 bbls
Total Proppant: 4,360,160 lbs
Silica Proppant: 4,360,160 lbs
Method for determining flowback: measuring flowback tank volumes | | Total fluid used in treatment (bbls): | 78391 | Max pressure during treatment (psi): | 4163 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 20 | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | 0.93 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 3921 | | Fresh water used in treatment (bbls): | 78391 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 4360160 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7007 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 7/12/2015 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 372 | | BBLS_OIL | 151 | | BTU_GAS | 1275 | | CALC_BBLS_H2O | 372 | | CALC_BBLS_OIL | 151 | | CALC_GOR | 1152 | | CALC_MCF_GAS | 174 | | CASING_PRESS | 1353 | | GRAVITY_OIL | 50 | | MCF_GAS | 174 | | TUBING_PRESS | 690 |
| | Perforation Data: | | Interval Top: | 7550 ft. | # Of Holes: | | | Interval Bottom: | 11383 ft. | Hole Size: | |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | Y | Noticed Date
01/29/2025 |
| Defined Inactive (SI) | Y | Last Production
09/30/2023 |
| Low Producing | Y | Production Period
01/2025 - 12/2025 |
| Total Oil Produced (Barrels) | 0 |
| Total Gas Produced (MCF) | 0 |
| GOR | |
| GOR Determination | |
| Average BOE per Day | 0.000 |
| Average MCFE per Day | 0.000 |
| Federal Financial Assurance | i | |
|
|
