COGIS

Facility Detail

COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-36591		Well Classification: OW Status: PA - 8/27/2025
Well Name/No:Land JG #31-18D
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date8/27/2025
FacilityID:431400LocationID:431392
Municipality/County:HUDSON / WELD #123Location:LOT2 31 2N64W 6
Field:WATTENBERG - #90750Elevation:4933 ft.
Basin:DENVER (DJ) BASIN
Planned Location:289FSL  909 FWLLat/Long: 40.088267 / -104.599425Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.088267 / -104.599426Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: AB - 8/27/2025             Measured TD: 7709 ft.    Vertical TD: 7375 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        AB - 8/27/2025
Wellbore PermitDIRECTIONAL
Permit #: Expiration Date:1/16/2015
Proposed Top PZ Location:Sec:31 Twp: 2N 64W Footage: 2016 FSL  575 FWL
Bottom Hole Location:Sec:31 Twp: 2N 64W Footage: 2016 FSL  575 FWL
Proposed Depth/Form:7690 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NB-CD , Formation: NIOBRARA-CODELL , Order: 407-87 , Unit Acreage: 80, Drill Unit: N2SW
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 1001 ft., Weight: 24 , Citings Type: PLANNED
Cement:Sacks: 463, Top: 0 ft., Bottom: 1001 ft.
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7690 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: 682, Top: 4045 ft., Bottom: 7690 ft.
Wellbore Completed
Completion Date:3/20/2013
Spud Date:3/16/2013Spud Date Is:ACTUAL
Measured TD:7709 ft.Measured PB depth:7681 ft.
True Vertical TD:7375 ft.True Vertical PB depth:7350 ft.
Bottom Hole Location:Sec:31 Twp: 2N 64WFootage: 2026 FSL  563 FWL
Log Types:Tiple Combination, CBL
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 1028 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 670, Top: 0 ft., Bottom: 1028 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7695 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 590, Top: 2350 ft., Bottom: 7695 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
PARKMAN4275 ft.4405 ft.NN
SUSSEX4840 ft.4949 ft.NN
SHANNON5494 ft.5553 ft.NN
SHARON SPRINGS7091 ft.NN
NIOBRARA7188 ft.NN
FORT HAYS7506 ft.NN
CODELL7530 ft.NN
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY08/27/2025
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveYNoticed Date
09/30/2024
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
