COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-36558		Well Classification: LO Status: AL - 1/28/2016
Well Name/No:Sievers #3-3-7-62
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:CARRIZO NIOBRARA LLC - 10439
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:ALStatus Date1/28/2016
FacilityID:431323LocationID:431322
County:WELD #123Location:SWSE 3 7N62W 6
Field:WILDCAT - #99999Elevation:4889 ft.
Basin:DENVER (DJ) BASIN
Planned Location:251FSL  1338 FELLat/Long: 40.596480 / -104.302220Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification:              Status: AL - 1/28/2016             Measured TD:

 Wellbore Data for Original WellboreWellbore Classification:         AL - 1/28/2016
Wellbore PermitHORIZONTAL
Permit #: Expiration Date:1/10/2015
Proposed Top PZ Location:Sec:3 Twp: 7N 62W Footage: 650 FSL  1950 FEL
Bottom Hole Location:Sec:3 Twp: 7N 62W Footage: 650 FNL  1950 FEL
Proposed Depth/Form:11014 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 407-642 , Unit Acreage: 640, Drill Unit: SECT 3 ALL
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1400 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 534, Top: 0 ft., Bottom: 1400 ft.
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 6820 ft., Weight: 23 , Citings Type: PLANNED
Cement:Sacks: 713, Top: 1400 ft., Bottom: 6820 ft.
Casing:String Type: 1ST LINER, Hole Size: 6.25 in., Size: 4.5 in., Top: 6105 ft., Depth: 11014 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: , Top: , Bottom:
Wellbore Completed
Completion Date:N/A
Measured TD:Measured PB depth:
True Vertical TD:True Vertical PB depth:
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
September 2024 - August 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
