Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-25817		Well Classification: GW Status: PA - 7/10/2024
Well Name/No:PEPPLER #17-22
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date7/10/2024
FacilityID:295832LocationID:310057
County:WELD #123Location:SENW 17 6N63W 6
Field:WATTENBERG - #90750Elevation:4681 ft.
Basin:DENVER (DJ) BASIN
Planned Location:1898FNL  2047 FWLLat/Long: 40.488660 / -104.462960Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.488670 / -104.462940Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: AB - 7/10/2024             Measured TD: 6993 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        AB - 7/10/2024
Wellbore Permit
Permit #:20081673 Expiration Date:4/28/2009
Proposed Depth/Form:7000 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NB-CD , Formation: NIOBRARA-CODELL , Order: , Unit Acreage: 80, Drill Unit: S2NW4
Wellbore Completed
Completion Date:5/8/2008
Spud Date:5/4/2008Spud Date Is:ACTUAL
Measured TD:6993 ft.Measured PB depth:6965 ft.
True Vertical TD:True Vertical PB depth:
Log Types:COMP.DENS.NEUTRON GR; DUAL IND. GR; CMNT BOND-VD
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 494 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 400, Top: 0 ft., Bottom: 494 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 6979 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 500, Top: 3120 ft., Bottom: 6979 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WASATCH G2700 ft.NN
PARKMAN3538 ft.NN
SUSSEX4305 ft.NN
SHANNON4905 ft.NN
NIOBRARA6589 ft.NN
FORT HAYS6836 ft.NN
CODELL6875 ft.NN

Formation CODL                     Formation Classification:  GW                     Status:  CM - 6/12/2008                 Interval Top: 6877 ft.    Interval Bottom: 6889 ft.

 Completed Information for Formation CODELL
1st Production Date:5/28/2008Choke Size:0.219 in.
Formation Name:CODELLCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:5/20/2008
Treatment Summary:FRAC CODELL W/4111 BBLS SLICKWATER & 115,000# 30/50 SAND. SPEARHEAD 500 BBLS 7% KCL AHEAD OF FRAC. TREAT @ AN AVERAGE OF 4784# 55 BPM. MAX PRESSURE 5127# MAX RATE 60.8 BPM.
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:6/12/2008Test Method:FLOWING
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 2
BBLS_OIL 50
BTU_GAS 1242
CALC_GOR 1680
CASING_PRESS 275
GRAVITY_OIL 46
MCF_GAS 84
Perforation Data:
Interval Top:6877 ft.# Of Holes:48
Interval Bottom:6889 ft.Hole Size:0.38 in.

Formation NBRR                     Formation Classification:  GW                     Status:  CM - 9/2/2008                  Interval Top: 6704 ft.    Interval Bottom: 6730 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:8/8/2008Choke Size:0.250 in.
Formation Name:NIOBRARACommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:8/6/2008
Treatment Summary:FRAC NIOBRARA WITH 4128 BBLS DYNAFLOW 2WR FLUID, AND 238000 30/50 SAND, AND 12000 20/40 RESIN COATED SAND. SPEARHEAD 24 BBLS 15% HCL ACID AHEAD OF FRAC. TREAT AT AN AVERAGE OF 4770 59.5BPM. MAX. PRESSURE 5185, MAX RATE 60.7BPM.
Tubing Size:2.375 in.Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:9/2/2008Test Method:FLOWING
Hours Tested:24Gas Type:SHALE
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 43
BBLS_OIL 90
BTU_GAS 1242
CALC_GOR 2044
CASING_PRESS 250
GRAVITY_OIL 47
MCF_GAS 184
Perforation Data:
Interval Top:6704 ft.# Of Holes:104
Interval Bottom:6730 ft.Hole Size:0.38 in.

Formation NB-CD                   Formation Classification:  GW                   Status:  AB - 7/10/2024                 Interval Top: 889 ft.    Interval Bottom: 6704 ft.

 Completed Information for Formation NIOBRARA-CODELL
1st Production Date:N/AChoke Size:
Formation Name:NIOBRARA-CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:5/8/2008
Treatment Summary:
Tubing Size:2.375 in.Tubing Setting Depth:6758 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:10/4/2008Test Method:FLOWING
Hours Tested:24Gas Type:SHALE
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 0
BBLS_OIL 31
BTU_GAS 1242
CALC_GOR 1806
CASING_PRESS 1100
GRAVITY_OIL 47
MCF_GAS 56
TUBING_PRESS 900
Perforation Data:
Interval Top:889 ft.# Of Holes:152
Interval Bottom:6704 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY07/10/2024
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveYNoticed Date
02/15/2024
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR DeterminationMCFE
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
