COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-21911		Well Classification: LO Status: AL - 10/27/2004
Well Name/No:SULLIVAN #43-26
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:ENCANA ENERGY RESOURCES INC - 100160
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:ALStatus Date10/27/2004
FacilityID:270595LocationID:333126
Municipality/County:FREDERICK / WELD #123Location:NESE 26 2N68W 6
Field:WATTENBERG - #90750Elevation:4969 ft.
Basin:DENVER (DJ) BASIN
Planned Location:2060FSL  580 FELLat/Long: 40.107847 / -104.963155Lat/Long Source: Calculated From Footages
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification:              Status: AL - 10/27/2004             Measured TD:

 Wellbore Data for Original WellboreWellbore Classification:         AL - 10/27/2004
Wellbore Permit
Permit #:20032427 Expiration Date:12/22/2004
Proposed Depth/Form:8200 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 407,407-66, Unit Acreage: 80, Drill Unit: E/2
Formation And Spacing:Code: JSND , Formation: J SAND , Order: 232,318A , Unit Acreage: 320, Drill Unit: S/2
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: 407 , Unit Acreage: 80, Drill Unit: E/2
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: , Depth: 850 ft., Weight: 24 , Citings Type: PLANNED
Cement:Sacks: 450, Top: 0 ft., Bottom: 850 ft.
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: , Depth: 8200 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: 250, Top: 6900 ft., Bottom: 8200 ft.
Casing:String Type: STAGE TOOL, Hole Size: , Size: , Top: , Depth: 5200 ft., Weight: , Citings Type: PLANNED
Cement:Sacks: 250, Top: 4100 ft., Bottom: 5200 ft.
Wellbore Completed
Completion Date:N/A
Measured TD:Measured PB depth:
True Vertical TD:True Vertical PB depth:
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
September 2024 - August 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
