COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-21349		Well Classification: OW Status: PA - 10/7/2024
Well Name/No:D.L. PHILLIPS #24-34
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date10/7/2024
FacilityID:266309LocationID:332757
Municipality/County:GREELEY / WELD #123Location:SESW 24 5N67W 6
Field:WATTENBERG - #90750Elevation:5024 ft.
Basin:DENVER (DJ) BASIN
Planned Location:453FSL  2171 FWLLat/Long: 40.378984 / -104.843294Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 40.379100 / -104.843180Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: AB - 10/7/2024             Measured TD: 7675 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        AB - 10/7/2024
Wellbore Permit
Permit #:20030218 Expiration Date:2/17/2004
Proposed Depth/Form:7675 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: CODL , Formation: CODELL , Order: 407-1 , Unit Acreage: 80, Drill Unit: E/2SW
Wellbore Completed
Completion Date:7/30/2003
Spud Date:6/21/2003Spud Date Is:ACTUAL
Measured TD:7675 ft.Measured PB depth:7608 ft.
True Vertical TD:True Vertical PB depth:
Log Types:DIL-COL-GR-CAL CBL
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 593 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 415, Top: 0 ft., Bottom: 593 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7653 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 125, Top: 6850 ft., Bottom: 7653 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
SUSSEX4570 ft.4636 ft.NN
SHANNON4964 ft.5031 ft.NN
NIOBRARA7214 ft.7443 ft.NN
CODELL7501 ft.7524 ft.NN

Formation CODL                     Formation Classification:  OW                     Status:  CM - 2/28/2007                 Interval Top: 7503 ft.    Interval Bottom: 7524 ft.

 Completed Information for Formation CODELL
1st Production Date:7/30/2003Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:2/8/2007
Treatment Summary:REFRAC'D CODELL W/241,590# 20/40 SAND USING 86,142 GAL 14# VISTAR
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:N/ATest Method:
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 10
BBLS_OIL 10
CALC_GOR 19200
CASING_PRESS 580
MCF_GAS 192
TUBING_PRESS 280
Perforation Data:
Interval Top:7503 ft.# Of Holes:84
Interval Bottom:7524 ft.Hole Size:0.42 in.

Formation NB-CD                   Formation Classification:  OW                   Status:  AB - 10/7/2024                 Interval Top: 7293 ft.    Interval Bottom: 7524 ft.

 Completed Information for Formation NIOBRARA-CODELL
1st Production Date:N/AChoke Size:0.250 in.
Formation Name:NIOBRARA-CODELLCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:7/30/2003
Treatment Summary:
Tubing Size:2.375 in.Tubing Setting Depth:7491 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:2/28/2007Test Method:FLOWING
Hours Tested:1Gas Type:SHALE
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 6
BBLS_OIL 3
CALC_GOR 14000
CASING_PRESS 650
MCF_GAS 42
TUBING_PRESS 450
Perforation Data:
Interval Top:7293 ft.# Of Holes:164
Interval Bottom:7524 ft.Hole Size:0.42 in.

Formation NBRR                     Formation Classification:  OW                     Status:  CM - 2/28/2007                 Interval Top: 7293 ft.    Interval Bottom: 7313 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:2/22/2007Choke Size:
Formation Name:NIOBRARACommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:2/8/2007
Treatment Summary:FRAC'D NIOBRARA W/241,590# 20/40 SAND USING 86,142 GAL 14# VISTAR
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation NBRR.
Perforation Data:
Interval Top:7293 ft.# Of Holes:80
Interval Bottom:7313 ft.Hole Size:0.42 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY10/07/2024
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
