COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-16108		Well Classification: GW Status: PA - 1/25/2021
Well Name/No:WHITE #27-5
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:69716
Facility Status:PAStatus Date1/25/2021
FacilityID:248310LocationID:328533
County:WELD #123Location:NENW 27 5N64W 6
Field:WATTENBERG - #90750Elevation:4589 ft.
Basin:DENVER (DJ) BASIN
Planned Location:638FNL  1976 FWLLat/Long: 40.375716 / -104.538214Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 40.376226 / -104.538210Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PA - 1/25/2021             Measured TD: 6910 ft.    Vertical TD: 0 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PA - 1/25/2021
Wellbore PermitDRIFTED
Permit #:921048 Expiration Date:12/22/1992
Proposed Depth/Form:
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:Not available
Unit: Unit Number:
Formation And Spacing:Code: NB-CD , Formation: NIOBRARA-CODELL , Order: 0 , Unit Acreage: 80, Drill Unit: E2NW
Wellbore Completed
Completion Date:10/16/1992
Measured TD:6910 ft.Measured PB depth:6879 ft.
True Vertical TD:0 ft.True Vertical PB depth:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 325 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 300, Top: 0 ft., Bottom: 325 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 3.5 in., Top: 0 ft., Depth: 6910 ft., Weight: 9.3 , Citings Type: ACTUAL
Cement:Sacks: 850, Top: 4050 ft., Bottom: 6910 ft., Determination Method: CBL
Casing:String Type: 2ND, Hole Size: 7 in., Size: 3.5 in., Top: 0 ft., Depth: 6910 ft., Weight: 9.3 , Citings Type: ACTUAL
Cement:Sacks: 850, Top: 4050 ft., Bottom: 6910 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
PARKMAN3454 ft.
SUSSEX4206 ft.
NIOBRARA6484 ft.
FORT HAYS6742 ft.
CODELL6767 ft.

Formation CODL                     Formation Classification:  GW                     Status:  CM - 12/1/2020                 Interval Top: 6768 ft.    Interval Bottom: 6778 ft.

 Completed Information for Formation CODELL
1st Production Date:10/28/1992Choke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:10/16/1992
Treatment Summary:FRACED CODELL FORMATION WITH 215,800# 20/40 SAND ALONG WITH 109,368 GALS. GELLED FLUID.
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:N/ATest Method:
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 2
BBLS_OIL 14
CALC_BBLS_H2O 8
CALC_BBLS_OIL 56
CALC_GOR 2714
CALC_MCF_GAS 152
CASING_PRESS 400
MCF_GAS 38
TUBING_PRESS 200
Perforation Data:
Interval Top:6768 ft.# Of Holes:80
Interval Bottom:6778 ft.Hole Size:0.38 in.

Formation NB-CD                   Formation Classification:  GW                   Status:  AB - 1/25/2021                 Interval Top: 6488 ft.    Interval Bottom: 6778 ft.

 Completed Information for Formation NIOBRARA-CODELL
1st Production Date:10/28/1992Choke Size:
Formation Name:NIOBRARA-CODELLCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:10/16/1992
Treatment Summary:NBRR 6484-6505, CODL 6767-6779.
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:N/ATest Method:
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 10
BBLS_OIL 32
CALC_BBLS_H2O 10
CALC_BBLS_OIL 32
CALC_GOR 3750
CALC_MCF_GAS 120
CASING_PRESS 700
MCF_GAS 120
Perforation Data:
Interval Top:6488 ft.# Of Holes:105
Interval Bottom:6778 ft.Hole Size:0.38 in.

Formation NBRR                     Formation Classification:  GW                     Status:  CM - 12/2/2020                 Interval Top: 6488 ft.    Interval Bottom: 6671 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:10/28/1992Choke Size:
Formation Name:NIOBRARACommingled:Yes
Production Method:
Open Hole Completion:No
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation NBRR.
Perforation Data:
Interval Top:6488 ft.# Of Holes:25
Interval Bottom:6671 ft.Hole Size:0.28 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY01/25/2021
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
