COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-12039		Well Classification: GW Status: PA - 8/25/2022
Well Name/No:GAMEWELL #34-1
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PDC ENERGY INC - 69175
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:69079
Facility Status:PAStatus Date8/25/2022
FacilityID:244245LocationID:322777
County:WELD #123Location:NWNE 34 5N64W 6
Field:WATTENBERG - #90750Elevation:4682 ft.
Basin:DENVER (DJ) BASIN
Planned Location:660FNL  1980 FELLat/Long: 40.361326 / -104.533374Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 40.361111 / -104.533333Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PA - 8/10/2022             Measured TD: 6930 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PA - 8/10/2022
Wellbore PermitDRIFTED
Permit #:841478 Expiration Date:2/8/1985
Proposed Depth/Form:
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:Not available
Unit: Unit Number:
Formation And Spacing:Code: NB-CD , Formation: NIOBRARA-CODELL , Order: 0 , Unit Acreage: 0, Drill Unit:
Wellbore Completed
Completion Date:N/A
Spud Date:10/20/1984Spud Date Is:ACTUAL
Measured TD:6930 ft.Measured PB depth:
True Vertical TD:True Vertical PB depth:
Log Types:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 247 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 280, Top: 0 ft., Bottom: 247 ft., Determination Method: VISU
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 6944 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 250, Top: 5950 ft., Bottom: 6944 ft., Determination Method: CBL
Casing:String Type: S.C. 1.1, Hole Size: , Size: , Top: , Depth: 5928 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 1069, Top: 640 ft., Bottom: 5928 ft., Determination Method: CBL
Casing:String Type: S.C. 1.2, Hole Size: , Size: , Top: , Depth: 528 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 200, Top: 0 ft., Bottom: 528 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
SUSSEX4255 ft.
SHANNON5168 ft.
NIOBRARA6620 ft.
FORT HAYS6785 ft.
CODELL6808 ft.
GREENHORN6862 ft.

Formation CODL                     Formation Classification:  GW                     Status:  CM - 3/6/2017                  Interval Top: 6838 ft.    Interval Bottom: 6851 ft.

 Completed Information for Formation CODELL
1st Production Date:N/AChoke Size:
Formation Name:CODELLCommingled:Yes
Production Method:
Open Hole Completion:
Formation Treatment
Treatment Date:12/22/1984
Treatment Summary:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation CODL.
Perforation Data:
Interval Top:6838 ft.# Of Holes:7
Interval Bottom:6851 ft.Hole Size:

Formation NB-CD                   Formation Classification:  GW                   Status:  AB - 8/25/2022                 Interval Top: 6560 ft.    Interval Bottom: 6851 ft.

 Completed Information for Formation NIOBRARA-CODELL
1st Production Date:4/14/2015Choke Size:
Formation Name:NIOBRARA-CODELLCommingled:No
Production Method:
Open Hole Completion:No
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
No Initial Test Data was found for formation NB-CD.
Perforation Data:
Interval Top:6560 ft.# Of Holes:367
Interval Bottom:6851 ft.Hole Size:0.42 in.

Formation NBRR                     Formation Classification:  GW                     Status:  CM - 3/6/2017                  Interval Top: 6560 ft.    Interval Bottom: 6740 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:N/AChoke Size:
Formation Name:NIOBRARACommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:8/13/2008
Treatment Summary:FRAC'D W/ 3,097 FRAC FLUID & 241,242# OTTAWA 30/50 SAND & 12,696# SB EXCEL 12/20 SAND.
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:N/ATest Method:
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 16
BBLS_OIL 44
BTU_GAS 1345
CALC_GOR 5545
CASING_PRESS 1000
GRAVITY_OIL 49
MCF_GAS 244
TUBING_PRESS 1200
Perforation Data:
Interval Top:6560 ft.# Of Holes:360
Interval Bottom:6740 ft.Hole Size:0.41 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY08/25/2022
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR DeterminationMCFE
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
