COGIS

Facility Detail

COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 This operator is no longer active in the State of Colorado.
 Surface Location
 API# 05-123-10166		Well Classification: OW Status: PA - 8/29/1985
Well Name/No:DAVID #1
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:ENERGY MINERALS CORP - 27550
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date8/29/1985
FacilityID:242375LocationID:407143
County:WELD #123Location:SWSE 36 1N67W 6
Field:WATTENBERG - #90750Elevation:4945 ft.
Planned Location:721FSL  1905 FELLat/Long: 40.002409 / -104.836350Lat/Long Source: Calculated From Footages
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PA - 8/29/1985             Measured TD: 4984 ft.    Vertical TD: 0 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PA - 8/29/1985
Wellbore Permit
Permit #:19810044 Expiration Date:5/9/1981
Proposed Depth/Form:4970 ft.
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:Not available
Unit: Unit Number:
Formation And Spacing:Code: SUSX , Formation: SUSSEX , Order: 0 , Unit Acreage: 40, Drill Unit: SWSE
Wellbore Completed
Completion Date:3/31/1981
Spud Date:12/16/1980Spud Date Is:ACTUAL
Measured TD:4984 ft.Measured PB depth:4969 ft.
True Vertical TD:0 ft.True Vertical PB depth:
Log Types:I-SFL, FDC-GR
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 227 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 200, Top: 0 ft., Bottom: , Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 4990 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 150, Top: 0 ft., Bottom: , Determination Method:
FormationInterval TopLog BottomCoredDSTs
FOX HILLS BASE944 ft.
SUSSEX4722 ft.

Formation SUSX                     Formation Classification:  GW                     Status:  AB - 8/29/1985                 Interval Top: 4828 ft.    Interval Bottom: 4842 ft.

 Completed Information for Formation SUSSEX
1st Production Date:4/23/1981Choke Size:0.219 in.
Formation Name:SUSSEXCommingled:No
Production Method:ROD PUMP
Open Hole Completion:
Formation Treatment
Treatment Date:3/31/1981
Treatment Summary:ACIDIZE W/2000 GALS 7.5% HY-CLEAN OVERDISPLACE W/25 BBLS 1.5% KCL FRAC W/60,000 GALS VERSA-GEL 2500 25,000# 20/40 SD & 105,000# 10/20 SD
Tubing Size:2.375 in.Tubing Setting Depth:4679 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:4/29/1981Test Method:ROD PUMP
Hours Tested:24Gas Type:
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 60
BBLS_OIL 14
CALC_GOR 3571
CASING_PRESS 220
MCF_GAS 50
Perforation Data:
Interval Top:4828 ft.# Of Holes:30
Interval Bottom:4842 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY08/29/1985
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
May 2024 - April 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
