COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-09244		Well Classification: OW Status: PA - 3/11/2010
Well Name/No:SELTZER #2-A
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PETERSON ENERGY OPERATING INC - 68710
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date3/11/2010
FacilityID:241455LocationID:333142
County:WELD #123Location:SWSW 34 1N67W 6
Field:SPINDLE - #77900Elevation:5091 ft.
Basin:DENVER (DJ) BASIN
Planned Location:580FSL  640 FWLLat/Long: 40.001989 / -104.883672Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 40.001920 / -104.883765Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PA - 3/11/2010             Measured TD: 5100 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PA - 3/11/2010
Wellbore Permit
Permit #:19770602 Expiration Date:10/22/1977
Proposed Depth/Form:5000 ft.
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:Not available
Unit: Unit Number:
Formation And Spacing:Code: SUSX , Formation: SUSSEX , Order: 0 , Unit Acreage: 80, Drill Unit: W2SW
Wellbore Completed
Completion Date:8/18/1977
Spud Date:6/28/1977Spud Date Is:ACTUAL
Measured TD:5100 ft.Measured PB depth:5041 ft.
True Vertical TD:True Vertical PB depth:
Log Types:IES - FDC/GR
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 168 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 125, Top: 0 ft., Bottom: 168 ft., Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 5100 ft., Weight: 10.5 , Citings Type: ACTUAL
Cement:Sacks: 200, Top: 3959 ft., Bottom: 5100 ft., Determination Method:
FormationInterval TopLog BottomCoredDSTs
SUSSEX4753 ft.

Formation SUSX                     Formation Classification:  GW                     Status:  AB - 3/11/2010                 Interval Top: 4926 ft.    Interval Bottom: 4988 ft.

 Completed Information for Formation SUSSEX
1st Production Date:8/18/1977Choke Size:0.594 in.
Formation Name:SUSSEXCommingled:No
Production Method:FLOWING
Open Hole Completion:
Formation Treatment
Treatment Date:8/18/1977
Treatment Summary:GEL WATER FRAC 62,500 GAL W/130,000# SD AT 24 BPM AT 1250 PSI, ISIP 930
Tubing Size:2.375 in.Tubing Setting Depth:4990 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:8/21/1977Test Method:FLOWING
Hours Tested:24Gas Type:
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 3
BBLS_OIL 73
CALC_GOR 1918
CASING_PRESS 800
GRAVITY_OIL 40
MCF_GAS 140
TUBING_PRESS 40
Perforation Data:
Interval Top:4926 ft.# Of Holes:
Interval Bottom:4988 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY03/11/2010
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
