COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITGIS Map GISOld GIS Map Old GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-123-07896		Well Classification: OW Status: PR - 4/23/1974
Well Name/No:DEVORE #2
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:KP KAUFFMAN COMPANY INC - 46290
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date4/23/1974
FacilityID:240108LocationID:332965
County:WELD #123Location:NESE 14 2N67W 6
Field:SPINDLE - #77900Elevation:4891 ft.
Basin:DENVER (DJ) BASIN
Planned Location:1980FSL  660 FELLat/Long: 40.136147 / -104.851052Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 40.136190 / -104.850970Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 4/23/1974             Measured TD: 4655 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 4/23/1974
Wellbore Permit
Permit #:19730850 Expiration Date:10/16/1974
Proposed Depth/Form:4700 ft.
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:Not available
Unit: Unit Number:
Formation And Spacing:Code: SUSX , Formation: SUSSEX , Order: 0 , Unit Acreage: 80, Drill Unit: N2SE
Wellbore Completed
Completion Date:4/16/1974
Spud Date:10/22/1973Spud Date Is:ACTUAL
Measured TD:4655 ft.Measured PB depth:4617 ft.
True Vertical TD:True Vertical PB depth:
Log Types:IES & COMPENSATED DENSITY W/GR
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 604 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 400, Top: 0 ft., Bottom: , Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 4653 ft., Weight: 10.5 , Citings Type: ACTUAL
Cement:Sacks: 200, Top: 0 ft., Bottom: , Determination Method:
FormationInterval TopLog BottomCoredDSTs
SUSSEX4497 ft.

Formation SUSX                     Formation Classification:  OW                     Status:  PR - 4/23/1974                 Interval Top: 4498 ft.    Interval Bottom: 4534 ft.

 Completed Information for Formation SUSSEX
1st Production Date:4/20/1974Choke Size:0.000 in.
Formation Name:SUSSEXCommingled:
Production Method:PUMPING
Open Hole Completion:
Tubing Size:2.375 in.Tubing Setting Depth:4627 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:4/23/1974Test Method:PUMPING
Hours Tested:4.5Gas Type:
Gas Disposal:VENTED
Test TypeMeasure
BBLS_H2O 1
BBLS_OIL 17
CALC_BBLS_H2O 6
CALC_BBLS_OIL 90
CALC_GOR 9560
CALC_MCF_GAS 860
CASING_PRESS 20
GRAVITY_OIL 42
MCF_GAS 161
Perforation Data:
Interval Top:4498 ft.# Of Holes:32
Interval Bottom:4534 ft.Hole Size:
Primary Well Designation:
Low Producing      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingYProduction Period
12/2024 - 11/2025

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
December 2024 - November 2025i
Total Oil Produced (Barrels)413
Total Gas Produced (MCF)594
GOR1438
GOR DeterminationBOE
Average BOE per Day1.411
Average MCFE per Day8.179

 Federal Financial Assurance  i

 Tribal Well  i No
