 Surface Location
 API# 05-123-07762		Well Classification: OW Status: PR - 10/1/2025
Well Name/No:NESSU #1
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:KP KAUFFMAN COMPANY INC - 46290
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date10/1/2025
FacilityID:239974LocationID:317790
County:WELD #123Location:SESE 17 2N66W 6
Field:SPINDLE - #77900Elevation:4940 ft.
Basin:DENVER (DJ) BASIN
Planned Location:660FSL  660 FELLat/Long: 40.132547 / -104.794060Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 40.132560 / -104.794000Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 10/1/2025             Measured TD: 4770 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 10/1/2025
Wellbore Permit
Permit #:19730467 Expiration Date:6/28/1974
Proposed Depth/Form:4740 ft.
Surface Mineral Owner Same:Not available
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: SUSX , Formation: SUSSEX , Order: 0 , Unit Acreage: 40, Drill Unit: SESE
Wellbore Completed
Completion Date:8/2/1973
Spud Date:6/30/1973Spud Date Is:ACTUAL
Measured TD:4770 ft.Measured PB depth:4731 ft.
True Vertical TD:True Vertical PB depth:
Log Types:SP-IES, FDC-DENSITY-GR-CALIPER
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 225 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 200, Top: 0 ft., Bottom: , Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 4768 ft., Weight: 10.5/11.6, Citings Type: ACTUAL
Cement:Sacks: 400, Top: 0 ft., Bottom: , Determination Method:
FormationInterval TopLog BottomCoredDSTs
SUSSEX4644 ft.

Formation SUSX                     Formation Classification:  GW                     Status:  PR - 10/1/2025                 Interval Top: 4652 ft.    Interval Bottom: 4674 ft.

 Completed Information for Formation SUSSEX
1st Production Date:7/17/1973Choke Size:0.000 in.
Formation Name:SUSSEXCommingled:
Production Method:PUMPING
Open Hole Completion:
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:8/2/1973Test Method:PUMPING
Hours Tested:24Gas Type:
Gas Disposal:VENTED
Test TypeMeasure
BBLS_H2O 18
BBLS_OIL 149
CALC_BBLS_H2O 18
CALC_BBLS_OIL 149
CALC_MCF_GAS 100
GRAVITY_OIL 45.4
MCF_GAS 100
Perforation Data:
Interval Top:4652 ft.# Of Holes:
Interval Bottom:4674 ft.Hole Size:
Primary Well Designation:
Low Producing      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingYProduction Period
10/2024 - 09/2025

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
