Wellbore #00 Wellbore Classification: GW Status: PR - 12/20/2018 Measured TD: 11164 ft. Vertical TD: 10844 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 12/20/2018 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 1/26/2020 | | Proposed Top PZ Location: | Sec:19 Twp: 2S 97W | Footage: 2374 FNL 1795 FWL | | Bottom Hole Location: | Sec:19 Twp: 2S 97W | Footage: 2374 FNL 1795 FWL | | Proposed Depth/Form: | 11337 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: ILES , Formation: ILES , Order: 527-4 , Unit Acreage: , Drill Unit: | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 527-1 , Unit Acreage: , Drill Unit: | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 60 ft., Weight: 55 , Citings Type: PLANNED | | Cement: | Sacks: 111, Top: 0 ft., Bottom: 60 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3663 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 595, Top: 1975 ft., Bottom: 3663 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 11337 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1358, Top: , Bottom: 11337 ft. | | Casing: | String Type: STAGE TOOL, Hole Size: , Size: 9.625 in., Top: , Depth: 1975 ft., Weight: , Citings Type: PLANNED | | Cement: | Sacks: 591, Top: 0 ft., Bottom: 1975 ft. |
| | |
| Wellbore Completed | | Completion Date: | 10/1/2018 | | Spud Date: | 9/19/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 11164 ft. | Measured PB depth: | 11101 ft. | | True Vertical TD: | 10844 ft. | True Vertical PB depth: | 10781 ft. | | Top PZ Location: | Sec:19 Twp: 2S 97W | Footage: 2366 FNL 1802 FWL | | Bottom Hole Location: | Sec:19 Twp: 2S 97W | Footage: 2376 FNL 1798 FWL | | Log Types: | CBL, MUD, PULSED NEUTRON (TRIPLE COMBO IN API 103-12301) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 81 ft., Weight: 87.5 , Citings Type: ACTUAL | | Cement: | Sacks: 75, Top: 0 ft., Bottom: 81 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3684 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1193, Top: 0 ft., Bottom: 3705 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 11144 ft., Weight: 13.5 , Citings Type: ACTUAL | | Cement: | Sacks: 1066, Top: 4820 ft., Bottom: 11164 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 4409 ft. | | N | N | | FORT UNION | 4847 ft. | | N | N | | OHIO CREEK | 6200 ft. | | N | N | | WILLIAMS FORK | 6200 ft. | | N | N | | CAMEO | 9664 ft. | | N | N | | ROLLINS | 10183 ft. | | N | N | | COZZETTE | 10339 ft. | | N | N | | CORCORAN | 10578 ft. | | N | N | | SEGO | 10877 ft. | | N | N |
Formation WFILS Formation Classification: GW Status: PR - 12/20/2018 Interval Top: 6519 ft. Interval Bottom: 11089 ft.| Completed Information for Formation WILLIAMS FORK-ILES | | 1st Production Date: | 12/9/2018 | Choke Size: | | | Formation Name: | WILLIAMS FORK-ILES | Commingled: | No | | Production Method: | | | Open Hole Completion: | Yes |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 11/1/2018 | Treatment End Date: | 11/24/2018 | | Treatment Summary: | Frac'd with 256,496 bbls 2% KCI slickwater and no proppant. Frac pair with Boies Ranch B-19N FED 43D-19-2-97 (API #05-103-12301). | | Total fluid used in treatment (bbls): | 256496 | Max pressure during treatment (psi): | 7433 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.40 | | Type Of gas: | | Number Of staged intervals: | 14 | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | 0.65 | | Recycled water used in treatment (bbls): | 230846 | Total flowback volume recovered (bbls): | 42294 | | Fresh water used in treatment (bbls): | 25650 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8810 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 12/20/2018 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 3819 | | BTU_GAS | 1039 | | CALC_BBLS_H2O | 3819 | | CALC_MCF_GAS | 2972 | | CASING_PRESS | 750 | | MCF_GAS | 2972 | | TUBING_PRESS | 2050 |
| | Perforation Data: | | Interval Top: | 6519 ft. | # Of Holes: | 756 | | Interval Bottom: | 11089 ft. | Hole Size: | 0.37 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 583 |
| Total Gas Produced (MCF) | 139049 |
| GOR | 238506 |
| GOR Determination | MCFE |
| Average BOE per Day | 67.270 |
| Average MCFE per Day | 390.146 |
| Federal Financial Assurance | i | Y |
|
|
