Wellbore #00 Wellbore Classification: GW Status: PR - 2/6/2019 Measured TD: 11028 ft. Vertical TD: 10891 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 2/6/2019 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 1/26/2020 | | Proposed Top PZ Location: | Sec:19 Twp: 2S 97W | Footage: 2257 FSL 1819 FWL | | Bottom Hole Location: | Sec:19 Twp: 2S 97W | Footage: 2257 FSL 1819 FWL | | Proposed Depth/Form: | 11122 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: ILES , Formation: ILES , Order: 527-4 , Unit Acreage: , Drill Unit: | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 527-1 , Unit Acreage: , Drill Unit: | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 60 ft., Weight: 55 , Citings Type: PLANNED | | Cement: | Sacks: 111, Top: 0 ft., Bottom: 60 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3568 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 584, Top: 1911 ft., Bottom: 3568 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 11122 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1337, Top: , Bottom: 11122 ft. | | Casing: | String Type: STAGE TOOL, Hole Size: , Size: 9.625 in., Top: , Depth: 1911 ft., Weight: , Citings Type: PLANNED | | Cement: | Sacks: 572, Top: 0 ft., Bottom: 1911 ft. |
| | |
| Wellbore Completed | | Completion Date: | 10/31/2018 | | Spud Date: | 9/5/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 11028 ft. | Measured PB depth: | 10993 ft. | | True Vertical TD: | 10891 ft. | True Vertical PB depth: | 10856 ft. | | Top PZ Location: | Sec:19 Twp: 2S 97W | Footage: 2278 FSL 1821 FWL | | Bottom Hole Location: | Sec:19 Twp: 2S 97W | Footage: 2260 FSL 1820 FWL | | Log Types: | CBL, MUD, PULSED NEUTRON (TRIPLE COMBO IN API 103-12301) | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 81 ft., Weight: 87.5 , Citings Type: ACTUAL | | Cement: | Sacks: 75, Top: 0 ft., Bottom: 81 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 3584 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1163, Top: 0 ft., Bottom: 3605 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 11006 ft., Weight: 13.5 , Citings Type: ACTUAL | | Cement: | Sacks: 1050, Top: 3970 ft., Bottom: 11028 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | OHIO CREEK | 6050 ft. | | N | N | | WILLIAMS FORK | 6050 ft. | | N | N | | CAMEO | 9413 ft. | | N | N | | ROLLINS | 9970 ft. | | N | N | | COZZETTE | 10117 ft. | | N | N | | CORCORAN | 10341 ft. | | N | N | | SEGO | 10613 ft. | | N | N |
Formation WFILS Formation Classification: GW Status: PR - 2/6/2019 Interval Top: 6663 ft. Interval Bottom: 10896 ft.| Completed Information for Formation WILLIAMS FORK-ILES | | 1st Production Date: | 1/22/2019 | Choke Size: | | | Formation Name: | WILLIAMS FORK-ILES | Commingled: | No | | Production Method: | | | Open Hole Completion: | Yes |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 12/24/2018 | Treatment End Date: | 1/12/2019 | | Treatment Summary: | Frac'd with 25,691 bbls of fresh water, 233,649 bbls of 2% KCI slickwater and no proppant. Frac pair with Boies Ranch B-19N FED 33B-19-2-97 (API #05-103-12302). | | Total fluid used in treatment (bbls): | 259610 | Max pressure during treatment (psi): | 7653 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.40 | | Type Of gas: | | Number Of staged intervals: | 14 | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | 0.68 | | Recycled water used in treatment (bbls): | 233649 | Total flowback volume recovered (bbls): | 78134 | | Fresh water used in treatment (bbls): | 25961 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8771 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 2/6/2019 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 4636 | | BTU_GAS | 1035 | | CALC_BBLS_H2O | 4636 | | CALC_MCF_GAS | 3374 | | CASING_PRESS | 725 | | MCF_GAS | 3374 | | TUBING_PRESS | 1300 |
| | Perforation Data: | | Interval Top: | 6663 ft. | # Of Holes: | 756 | | Interval Bottom: | 10896 ft. | Hole Size: | 0.37 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 445 |
| Total Gas Produced (MCF) | 105000 |
| GOR | 235955 |
| GOR Determination | MCFE |
| Average BOE per Day | 50.803 |
| Average MCFE per Day | 294.650 |
| Federal Financial Assurance | i | Y |
|
|
