COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-103-10812		Well Classification: GW Status: PR - 11/1/2019
Well Name/No:PICEANCE CREEK UNIT #297-15A4
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:COD052141
Facility Status:PRStatus Date11/1/2019
FacilityID:285542LocationID:335895
County:RIO BLANCO #103Location:NENW 15 2S97W 6
Field:PICEANCE CREEK - #68800Elevation:6622 ft.
Basin:PICEANCE BASIN
Planned Location:1163FNL  1710 FWLLat/Long: 39.880825 / -108.271317Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.880826 / -108.271319Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 11/1/2019             Measured TD: 12400 ft.    Vertical TD: 12062 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 11/1/2019
Wellbore PermitDIRECTIONAL
Permit #:20083200 Expiration Date:6/16/2009
Proposed Top PZ Location:Sec:15 Twp: 2S 97W Footage: 1375 FNL  1990 FEL
Bottom Hole Location:Sec:15 Twp: 2S 97W Footage: 1375 FNL  1990 FEL
Proposed Depth/Form:14000 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEDERALSurface Owner:FEDERAL
Unit:PICEANCE CREEK Unit Number:COC47666X
Formation And Spacing:Code: MVRD , Formation: MESAVERDE , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: OHCRK , Formation: OHIO CREEK , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: WSTC , Formation: WASATCH , Order: , Unit Acreage: , Drill Unit:
Wellbore Completed
Completion Date:8/3/2009
Spud Date:7/12/2009Spud Date Is:ACTUAL
Measured TD:12400 ft.Measured PB depth:12243 ft.
True Vertical TD:12062 ft.True Vertical PB depth:12003 ft.
Top PZ Location:Sec:15 Twp: 2S 97WFootage: 1375 FNL  1990 FEL
Bottom Hole Location:Sec:15 Twp: 2S 97WFootage: 1375 FNL  1990 FEL
Log Types:
Log Types:MUD LOGS, IMAGING BEHIND CASING - ULTRASONIC TOOL, RA BOND, GASVIEW, RPM
Log Types:
Log Types:
Casing:String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 120 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 96, Top: 0 ft., Bottom: 12 ft., Determination Method: CALC
Casing:String Type: SURF, Hole Size: 14.75 in., Size: 10.75 in., Top: 0 ft., Depth: 1168 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 840, Top: 0 ft., Bottom: 1168 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 9.875 in., Size: 7 in., Top: 0 ft., Depth: 8404 ft., Weight: 26 , Citings Type: ACTUAL
Cement:Sacks: 1290, Top: 3314 ft., Bottom: 8404 ft., Determination Method: CALC
Casing:String Type: 2ND, Hole Size: 6.125 in., Size: 4.5 in., Top: 0 ft., Depth: 12406 ft., Weight: 15.1 , Citings Type: ACTUAL
Cement:Sacks: 905, Top: 6150 ft., Bottom: 12406 ft., Determination Method: CALC
Casing:String Type: STAGE TOOL, Hole Size: 9.875 in., Size: 7 in., Top: , Depth: 3852 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 1180, Top: 1168 ft., Bottom: 3852 ft., Determination Method: CALC
FormationInterval TopLog BottomCoredDSTs
WASATCH G5407 ft.7159 ft.NN
OHIO CREEK7159 ft.7213 ft.NN
WILLIAMS FORK - CAMEO7213 ft.11183 ft.NN
ROLLINS11183 ft.11334 ft.NN
COZZETTE11334 ft.11650 ft.NN
CORCORAN11650 ft.12400 ft.NN

Formation CRCRN                   Formation Classification:  GW                   Status:  PR - 11/1/2019                 Interval Top: 11660 ft.    Interval Bottom: 11991 ft.

 Completed Information for Formation CORCORAN
1st Production Date:9/11/2009Choke Size:0.297 in.
Formation Name:CORCORANCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:8/27/2009
Treatment Summary:FRAC W/134,700# PROPPANT (22,500# 100 MESH & 112,200# 40/70).
Tubing Size:2.375 in.Tubing Setting Depth:10377 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:9/24/2009Test Method:FLOWING
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BTU_GAS 1040
CALC_BBLS_H2O 380
CALC_BBLS_OIL 0
CALC_GOR 0
CALC_MCF_GAS 308
CASING_PRESS 2459
GRAVITY_OIL 53
Perforation Data:
Interval Top:11660 ft.# Of Holes:80
Interval Bottom:11991 ft.Hole Size:0.32 in.

Formation COZZ                     Formation Classification:  GW                     Status:  PR - 11/1/2019                 Interval Top: 11484 ft.    Interval Bottom: 11582 ft.

 Completed Information for Formation COZZETTE
1st Production Date:9/11/2009Choke Size:0.297 in.
Formation Name:COZZETTECommingled:Yes
Production Method:
Open Hole Completion:Yes
Formation Treatment
Treatment Date:8/27/2009
Treatment Summary:FRAC W/56,200# PROPPANT (46,800# 40/70 & 9,400# 100 MESH).
Tubing Size:2.375 in.Tubing Setting Depth:10377 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:9/24/2009Test Method:FLOWING
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BTU_GAS 1040
CALC_BBLS_H2O 160
CALC_BBLS_OIL 0
CALC_GOR 0
CALC_MCF_GAS 130
CASING_PRESS 2954
GRAVITY_OIL 53
Perforation Data:
Interval Top:11484 ft.# Of Holes:32
Interval Bottom:11582 ft.Hole Size:0.32 in.

Formation WFCM                     Formation Classification:  GW                     Status:  PR - 11/1/2019                 Interval Top: 9178 ft.    Interval Bottom: 11094 ft.

 Completed Information for Formation WILLIAMS FORK - CAMEO
1st Production Date:9/11/2009Choke Size:0.297 in.
Formation Name:WILLIAMS FORK - CAMEOCommingled:Yes
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:8/27/2009
Treatment Summary:FRAC W/960,600# PROPPANT (797,500# 40/70 & 163, 100# 100 MESH). FRAC PLUGS @ 10,885'; 10,780'; 10,088' & 9,404'. DO ALL PLUGS.
Tubing Size:2.375 in.Tubing Setting Depth:10377 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:9/24/2009Test Method:FLOWING
Hours Tested:24Gas Type:WET
Gas Disposal:SOLD
Test TypeMeasure
BTU_GAS 1040
CALC_BBLS_H2O 2009
CALC_BBLS_OIL 0
CALC_GOR 0
CALC_MCF_GAS 1629
CASING_PRESS 2459
GRAVITY_OIL 53
Perforation Data:
Interval Top:9178 ft.# Of Holes:352
Interval Bottom:11094 ft.Hole Size:0.32 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)61782
GOR
GOR DeterminationMCFE
Average BOE per Day29.179
Average MCFE per Day169.253

 Federal Financial Assurance  i Y

 Tribal Well  i No
