COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-103-09129		Well Classification: GW Status: PR - 6/1/2025
Well Name/No:GOVERNMENT #298-27-3
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:TEP ROCKY MOUNTAIN LLC - 96850
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:47726
Facility Status:PRStatus Date6/1/2025
FacilityID:231459LocationID:315725
County:RIO BLANCO #103Location:SESE 27 2S98W 6
Field:SULPHUR CREEK - #80090Elevation:6775 ft.
Basin:PICEANCE BASIN
Planned Location:146FSL  146 FELLat/Long: 39.840362 / -108.372398Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 39.840190 / -108.372450Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 6/1/2025             Measured TD: 4600 ft.    Vertical TD: 4600 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 6/1/2025
Wellbore Permit
Permit #:831708 Expiration Date:4/21/1984
Proposed Depth/Form:
Surface Mineral Owner Same:Not available
Mineral Owner:FEDERALSurface Owner:Not available
Unit: Unit Number:C-033315
Formation And Spacing:Code: WSTCG , Formation: WASATCH G , Order: 0 , Unit Acreage: 0, Drill Unit:
Wellbore Completed
Completion Date:6/20/1984
Spud Date:5/14/1984Spud Date Is:ACTUAL
Measured TD:4600 ft.Measured PB depth:4549 ft.
True Vertical TD:4600 ft.True Vertical PB depth:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 319 ft., Weight: 36 , Citings Type: ACTUAL
Cement:Sacks: 180, Top: 0 ft., Bottom: 319 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 4600 ft., Weight: 15.5 , Citings Type: ACTUAL
Cement:Sacks: 475, Top: 1156 ft., Bottom: 4600 ft., Determination Method: CBL
Casing:String Type: S.C. 1.1, Hole Size: 7.875 in., Size: 5.5 in., Top: , Depth: 0 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 200, Top: , Bottom: , Determination Method: BH
FormationInterval TopLog BottomCoredDSTs
WASATCH4279 ft.

Formation WSTCG                   Formation Classification:  GW                   Status:  PR - 6/1/2025                  Interval Top: 4282 ft.    Interval Bottom: 4292 ft.

 Completed Information for Formation WASATCH G
1st Production Date:N/AChoke Size:0.000 in.
Formation Name:WASATCH GCommingled:
Production Method:
Open Hole Completion:
Tubing Size:1.25 in.Tubing Setting Depth:4308 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:6/30/1984Test Method:FLOWING
Hours Tested:120Gas Type:
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 10
CALC_MCF_GAS 2600
MCF_GAS 1634
Perforation Data:
Interval Top:4282 ft.# Of Holes:20
Interval Bottom:4292 ft.Hole Size:0.48 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
November 2024 - October 2025i
Total Oil Produced (Barrels)7
Total Gas Produced (MCF)4422
GOR631714
GOR DeterminationMCFE
Average BOE per Day2.109
Average MCFE per Day12.242

 Federal Financial Assurance  i Y

 Tribal Well  i No
