Wellbore #00 Wellbore Classification: GW Status: PR - 4/14/2025 Measured TD: 8500 ft. Vertical TD: 8492 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 4/14/2025 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 3/16/2026 | | Proposed Top PZ Location: | Sec:25 Twp: 9S 93W | Footage: 2533 FNL 681 FEL | | Bottom Hole Location: | Sec:25 Twp: 9S 93W | Footage: 2533 FNL 681 FEL | | Proposed Depth/Form: | 8503 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WFILS , Formation: WILLIAMS FORK-ILES , Order: 369-12 , Unit Acreage: 640, Drill Unit: Section 25:ALL | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 60 ft., Weight: 36.94 , Citings Type: PLANNED | | Cement: | Sacks: 150, Top: 0 ft., Bottom: 60 ft. | | Casing: | String Type: SURF, Hole Size: 11 in., Size: 8.625 in., Top: 0 ft., Depth: 1530 ft., Weight: 24 , Citings Type: PLANNED | | Cement: | Sacks: 264, Top: 0 ft., Bottom: 1530 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 8503 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1260, Top: 2700 ft., Bottom: 8503 ft. |
| | |
| Wellbore Completed | | Completion Date: | 2/8/2025 | | Spud Date: | 2/5/2025 | Spud Date Is: | ACTUAL | | Measured TD: | 8500 ft. | Measured PB depth: | 8434 ft. | | True Vertical TD: | 8492 ft. | True Vertical PB depth: | 8426 ft. | | Top PZ Location: | Sec:25 Twp: 9S 93W | Footage: 2487 FNL 709 FEL | | Bottom Hole Location: | Sec:25 Twp: 9S 93W | Footage: 2529 FNL 685 FEL | | Log Types: | CNL, RBL (RES in API 077-10590 & 077-10609) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 110 ft., Weight: 36.94 , Citings Type: ACTUAL | | Cement: | Sacks: 150, Top: 0 ft., Bottom: 110 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 11 in., Size: 8.625 in., Top: 0 ft., Depth: 1616 ft., Weight: 24 , Citings Type: ACTUAL | | Cement: | Sacks: 254, Top: 0 ft., Bottom: 1616 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 8480 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 848, Top: 1583 ft., Bottom: 8480 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH | 30 ft. | 3253 ft. | N | N | | WASATCH G | 3253 ft. | 3667 ft. | N | N | | FORT UNION | 3667 ft. | 5203 ft. | N | N | | OHIO CREEK | 5203 ft. | 5553 ft. | N | N | | WILLIAMS FORK | 5553 ft. | 7903 ft. | N | N | | CAMEO | 7903 ft. | 8283 ft. | N | N | | CAMEO COAL | 8283 ft. | 8303 ft. | N | N | | ROLLINS | 8303 ft. | 8500 ft. | N | N |
Formation WFCM Formation Classification: OW Status: PR - 4/14/2025 Interval Top: 6464 ft. Interval Bottom: 8177 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 3/17/2025 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | HYDRAULIC FRACTURING | | Treatment Date: | 3/17/2025 | Treatment End Date: | 3/22/2025 | | Treatment Summary: | 67000 BBLS Slickwater No Proppant | | Total fluid used in treatment (bbls): | 67000 | Max pressure during treatment (psi): | 7317 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.34 | | Type Of gas: | | Number Of staged intervals: | 7 | | Total acid used in treatment (bbls): | 0 | Min frac gradient (psi/ft): | 0.55 | | Recycled water used in treatment (bbls): | 56382 | Total flowback volume recovered (bbls): | 31509 | | Fresh water used in treatment (bbls): | 10618 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | 0 | Green completions techniques utilized: | -- | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7819 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/14/2025 | Test Method: | Flowing | | Hours Tested: | 1 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1330 | | CALC_MCF_GAS | 41 | | CASING_PRESS | 1526 | | GRAVITY_OIL | 1 | | MCF_GAS | 994 | | TUBING_PRESS | 941 |
| | Perforation Data: | | Interval Top: | 6464 ft. | # Of Holes: | 204 | | Interval Bottom: | 8177 ft. | Hole Size: | 3.125 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 71 |
| Total Gas Produced (MCF) | 121743 |
| GOR | 1714690 |
| GOR Determination | MCFE |
| Average BOE per Day | 0.000 |
| Average MCFE per Day | 0.000 |
| Federal Financial Assurance | i | |
|
|
