COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-073-06358		Well Classification: OW Status: PR - 7/27/2013
Well Name/No:SNOWBIRD #9-15
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:POLARIS PRODUCTION OPCO LLC - 10793
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date7/27/2013
FacilityID:300127LocationID:309652
County:LINCOLN #073Location:NESE 15 6S54W 6
Field:ARIKAREE CREEK - #2914Elevation:5195 ft.
Planned Location:2332FSL  717 FELLat/Long: 39.527610 / -103.419100Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.527610 / -103.419100Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 7/27/2013             Measured TD: 8483 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 7/27/2013
Wellbore Permit
Permit #: Expiration Date:9/25/2014
Proposed Depth/Form:8500 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: ABCK , Formation: ARBUCKLE , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: ATOK , Formation: ATOKA , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: CHRK , Formation: CHEROKEE , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: KEYES , Formation: KEYES , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: LNSNG , Formation: LANSING , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: MRRW , Formation: MORROW , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: MRTN , Formation: MARMATON , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: MSSP , Formation: MISSISSIPPIAN , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: SPGN , Formation: SPERGEN , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 400 ft., Weight: 24 , Citings Type: PLANNED
Cement:Sacks: 250, Top: 0 ft., Bottom: 400 ft.
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 8500 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 583, Top: 3619 ft., Bottom: 8500 ft.
Casing:String Type: 2ND, Hole Size: 7.875 in., Size: 5.5 in., Top: , Depth: 8400 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 522, Top: 2500 ft., Bottom: 8400 ft.
Wellbore Completed
Completion Date:5/23/2013
Spud Date:5/23/2013Spud Date Is:ACTUAL
Measured TD:8483 ft.Measured PB depth:8388 ft.
True Vertical TD:True Vertical PB depth:
Log Types:MainPass.las, Combinable Magnetic Resonance, Induction, LithoScanner, Triple Combo, Laterolog, Microlog, Nuclear Print, Sonic, CBL, Production Cement Report and Surface Cement Report
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 336 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 90, Top: 0 ft., Bottom: 336 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 8483 ft., Weight: 17 , Citings Type: ACTUAL
Cement:Sacks: 1175, Top: 180 ft., Bottom: 8483 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
LANSING-KANSAS CITY6860 ft.
MARMATON7194 ft.7299 ft.
CHEROKEE7368 ft.7389 ft.
ATOKA7568 ft.
MORROW7796 ft.
KEYES7940 ft.7972 ft.
SPERGEN8046 ft.8483 ft.

Formation SPGN                     Formation Classification:  OW                     Status:  PR - 7/27/2013                 Interval Top: 8046 ft.    Interval Bottom: 8222 ft.

 Completed Information for Formation SPERGEN
1st Production Date:7/27/2013Choke Size:
Formation Name:SPERGENCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Type:
Treatment Date:7/27/2013Treatment End Date:N/A
Treatment Summary:No treatment was done on this formation.
Total fluid used in treatment (bbls):Max pressure during treatment (psi):
Total gas used in treatment (mcf):Fluid density (lbs/gal):
Type Of gas:Number Of staged intervals:
Total acid used in treatment (bbls):Min frac gradient (psi/ft):
Recycled water used in treatment (bbls):Total flowback volume recovered (bbls):
Fresh water used in treatment (bbls):Disposition method For flowback:
Total proppant used (lbs):Green completions techniques utilized:--
Reason green techniques Not utilized:
Tubing Size:2.875 in.Tubing Setting Depth:7962 ft.
Tubing Packer Depth:7748 ft.Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:7/27/2013Test Method:Pumping
Hours Tested:24Gas Type:WET
Gas Disposal:VENTED
Test TypeMeasure
BBLS_H2O 153
BBLS_OIL 159
BTU_GAS 565
CALC_BBLS_H2O 153
CALC_BBLS_OIL 159
CALC_GOR 176
CALC_MCF_GAS 27
GRAVITY_OIL 38
MCF_GAS 27
TUBING_PRESS 75
Perforation Data:
Interval Top:8046 ft.# Of Holes:400
Interval Bottom:8222 ft.Hole Size:0.52 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
April 2024 - March 2025i
Total Oil Produced (Barrels)7643
Total Gas Produced (MCF)503
GOR65
GOR DeterminationBOE
Average BOE per Day20.693
Average MCFE per Day120.035

 Federal Financial Assurance  i

 Tribal Well  i No
