COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-073-06318		Well Classification: OW Status: PA - 11/21/2013
Well Name/No:CRAIG #15-32H
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:NIGHTHAWK PRODUCTION LLC - 10399
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date11/21/2013
FacilityID:294990LocationID:309617
County:LINCOLN #073Location:SWSE 32 13S55W 6
Field:BOLERO - #7153Elevation:5112 ft.
Basin:DENVER (DJ) BASIN
Planned Location:455FSL  2008 FELLat/Long: 38.866600 / -103.578070Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 38.866600 / -103.578070Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PA - 11/21/2013             Measured TD: 7751 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PA - 11/21/2013
Wellbore Permit
Permit #:20080387 Expiration Date:3/13/2009
Bottom Hole Location:Sec:32 Twp: 13S 55W Footage: 1968 FSL  1984 FEL
Proposed Depth/Form:8000 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: MSSP , Formation: MISSISSIPPIAN , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: 2ND, Hole Size: 7.875 in., Size: 5.5 in., Top: , Depth: 8000 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 497, Top: 2500 ft., Bottom: 8000 ft.
Wellbore Completed
Completion Date:10/2/2008
Spud Date:9/22/2008Spud Date Is:ACTUAL
Measured TD:7751 ft.Measured PB depth:7664 ft.
True Vertical TD:True Vertical PB depth:
Bottom Hole Location:Sec:32 Twp: 13S 55WFootage: 1968 FSL  1984 FEL
Log Types:PULSE NEWTRON GAMMA RAY, CBL
Casing:String Type: SURF, Hole Size: 17.5 in., Size: 13.375 in., Top: , Depth: 363 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 325, Top: 0 ft., Bottom: 363 ft., Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: , Depth: 7729 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 300, Top: 6256 ft., Bottom: 7729 ft., Determination Method: CBL
Casing:String Type: S.C. 1.1, Hole Size: , Size: 5.5 in., Top: , Depth: 3772 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 150, Top: 3570 ft., Bottom: 3772 ft., Determination Method: CBL
Casing:String Type: S.C. 1.2, Hole Size: , Size: 5.5 in., Top: , Depth: , Weight: , Citings Type: ACTUAL
Cement:Sacks: 150, Top: 2940 ft., Bottom: 3570 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
D SAND3266 ft.NN
MARMATON6284 ft.NN
CHEROKEE6534 ft.NN
ATOKA6781 ft.NN
MORROW7207 ft.NN
ST LOUIS7518 ft.NN
ARBUCKLE7649 ft.NN

Formation ATOK                     Formation Classification:  GW                     Status:  AB - 7/15/2009                 Interval Top: 6532 ft.    Interval Bottom: 6683 ft.

 Completed Information for Formation ATOKA
1st Production Date:12/3/2008Choke Size:
Formation Name:ATOKACommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:10/30/2008
Treatment Summary:PERF CHEROKEE FM 6668-6680, 6647-6664,6594-6564 & 6544-6532, TOTAL 141 HOLES. FRAC CHEROKEE WITH 12735 BBL SLICKWATER, 118830LBS 40/70 SAND AND 840 GAL 15% HCL (IN LOWER PERFS), MAXIMUM PRESSURE 4523 PSI.
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:11/5/2008Test Method:
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 3
BBLS_OIL 8
BTU_GAS 1130
GRAVITY_OIL 33
Perforation Data:
Interval Top:6532 ft.# Of Holes:93
Interval Bottom:6683 ft.Hole Size:0.4 in.

Formation MRTN                     Formation Classification:  GW                     Status:  AB - 7/15/2009                 Interval Top: 6470 ft.    Interval Bottom: 6472 ft.

 Completed Information for Formation MARMATON
1st Production Date:N/AChoke Size:
Formation Name:MARMATONCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:1/20/2009
Treatment Summary:PERF MARMATON FM 6474-6470, TOTAL 12 HOLES. ACIDIZE FM WITH 17.9 BBLS 15% HCL AND 217.5 BBL FLUSH FLUID. MAXIMUM PRESSURE 8.2 PSI.
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:2/11/2009Test Method:SWAB TEST
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BTU_GAS 1115
GRAVITY_OIL 39
MCF_GAS 87
Perforation Data:
Interval Top:6470 ft.# Of Holes:12
Interval Bottom:6472 ft.Hole Size:0.4 in.

Sidetrack #01             Wellbore Classification: OW             Status: PA - 11/21/2013             Measured TD: 8554 ft.

 Wellbore Data for Sidetrack #01Wellbore Classification: OW        PA - 11/21/2013
Wellbore PermitDIRECTIONAL
Permit #:20092604 Expiration Date:7/9/2011
Proposed Top PZ Location:Sec: Twp: Footage: 444 FSL  2019 FEL
Bottom Hole Location:Sec:32 Twp: 13S 55W Footage: 500 FSL  1997 FEL
Proposed Depth/Form:7006 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: MRRW , Formation: MORROW , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: MSSP , Formation: MISSISSIPPIAN , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: PENN , Formation: PENNSYLVANIAN , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: 1ST LINER, Hole Size: 4.75 in., Size: 4 in., Top: , Depth: 7006 ft., Weight: 11 , Citings Type: PLANNED
Cement:Sacks: 150, Top: 6200 ft., Bottom: 7006 ft.
Wellbore Completed
Completion Date:10/31/2009
Spud Date:9/18/2009Spud Date Is:ACTUAL
Measured TD:8554 ft.Measured PB depth:
True Vertical TD:True Vertical PB depth:6442 ft.
Top PZ Location:Sec:32 Twp: 13S 55WFootage: 455 FSL  2008 FEL
Bottom Hole Location:Sec:32 Twp: 13S 55WFootage: 455 FSL  2008 FEL
Log Types:NO LOGS IN "OH" OF SIDETRACK
Casing:String Type: SURF, Hole Size: 17.5 in., Size: 13.375 in., Top: , Depth: 363 ft., Weight: 54.5 , Citings Type: ACTUAL
Cement:Sacks: 325, Top: 0 ft., Bottom: 363 ft., Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: , Depth: 7729 ft., Weight: 17 , Citings Type: ACTUAL
Cement:Sacks: 300, Top: 6258 ft., Bottom: 7729 ft., Determination Method: CBL
Casing:String Type: S.C. 1.1, Hole Size: , Size: , Top: , Depth: 3772 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 150, Top: 3570 ft., Bottom: 4480 ft., Determination Method: CBL
Casing:String Type: S.C. 1.2, Hole Size: , Size: , Top: , Depth: 3550 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 150, Top: 2940 ft., Bottom: 3570 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
D SAND3266 ft.NN
MARMATON6284 ft.NN

Formation CHRK                     Formation Classification:  GW                     Status:  AB - 11/21/2013                Interval Top: 7266 ft.    Interval Bottom: 8554 ft.

 Completed Information for Formation CHEROKEE
1st Production Date:3/5/2010Choke Size:
Formation Name:CHEROKEECommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:12/21/2009
Treatment Summary:USE COIL TBG TO CLEANOUT, UNABLE TO MAKE HOLE. PRODUCTION STRING PARTED IN LATERAL. PART IS AT 7,046' (MD). RAN PUMP AND RODS; SET IN VERTICAL PORTION, PUMP DEPTH 6,035'.
Tubing Size:2.875 in.Tubing Setting Depth:8435 ft.
Tubing Packer Depth:6036 ft.Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:5/4/2010Test Method:PUMPING
Hours Tested:24Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 35
BBLS_OIL 7
CALC_BBLS_H2O 35
CALC_BBLS_OIL 7
CALC_GOR 0
CALC_MCF_GAS 0
GRAVITY_OIL 39
MCF_GAS 0
Perforation Data:
Interval Top:7266 ft.# Of Holes:
Interval Bottom:8554 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY11/21/2013
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
