Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-071-09757		Well Classification: GW Status: PA - 5/21/2025
Well Name/No:GOLDEN EAGLE #17-15H
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:OGRIS OPERATING LLC - 10758
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PAStatus Date5/21/2025
FacilityID:301623LocationID:386829
County:LAS ANIMAS #071Location:SWSE 17 33S67W 6
Field:PURGATOIRE RIVER - #70830Elevation:7764 ft.
Basin:RATON BASIN
Planned Location:684FSL  1734 FELLat/Long: 37.167077 / -104.907916Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 37.167079 / -104.907917Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: AB - 5/21/2025             Measured TD: 905 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        AB - 5/21/2025
Wellbore PermitHORIZONTAL
Permit #:20087397 Expiration Date:2/17/2010
Proposed Top PZ Location:Sec: Twp: Footage: 684 FSL  1734 FEL
Bottom Hole Location:Sec:17 Twp: 33S 67W Footage: 580 FSL  1025 FWL
Proposed Depth/Form:7534 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: SURF, Hole Size: 17.5 in., Size: 13.375 in., Top: , Depth: 880 ft., Weight: 48 , Citings Type: PLANNED
Cement:Sacks: 411, Top: 0 ft., Bottom: 880 ft.
Casing:String Type: 1ST, Hole Size: 12.25 in., Size: 9.625 in., Top: , Depth: 4200 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 960, Top: 0 ft., Bottom: 4200 ft.
Casing:String Type: 2ND, Hole Size: 8.75 in., Size: 7 in., Top: , Depth: 5584 ft., Weight: 23 , Citings Type: PLANNED
Cement:Sacks: 142, Top: 0 ft., Bottom: 5584 ft.
Casing:String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: , Depth: 7534 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: 0, Top: , Bottom: 7534 ft.
Wellbore Completed
Completion Date:N/A
Spud Date:2/11/2010Spud Date Is:ACTUAL
Measured TD:905 ft.Measured PB depth:
True Vertical TD:True Vertical PB depth:
Bottom Hole Location:Sec:17 Twp: 33S 67WFootage: 580 FSL  1025 FWL
Log Types:
Casing:String Type: CONDUCTOR, Hole Size: , Size: , Top: 0 ft., Depth: 41 ft., Weight: 106.5 , Citings Type: ACTUAL
Cement:Sacks: 96, Top: 0 ft., Bottom: 41 ft., Determination Method: VISU
Casing:String Type: SURF, Hole Size: 17.5 in., Size: 13.375 in., Top: 0 ft., Depth: 894 ft., Weight: 48 , Citings Type: ACTUAL
Cement:Sacks: 510, Top: 0 ft., Bottom: 905 ft., Determination Method: VISU
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedY05/21/2025
Out Of Service RepurposedN
Out Of ServiceYPlugging Due Date
12/04/2028
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR DeterminationMCFE
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
