Wellbore #00 Wellbore Classification: OW Status: PR - 3/1/2025 Measured TD: 13558 ft. Vertical TD: 7081 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 3/1/2025 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 4/2/2017 | | Proposed Top PZ Location: | Sec:12 Twp: 5N 68W | Footage: 2331 FSL 12 FEL | | Bottom Hole Location: | Sec:11 Twp: 5N 68W | Footage: 2218 FSL 499 FEL | | Proposed Depth/Form: | 13456 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: 480, Drill Unit: GWA | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 704 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 270, Top: 0 ft., Bottom: 704 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 13456 ft., Weight: 17 , Citings Type: PLANNED | | Cement: | Sacks: 1500, Top: , Bottom: 13456 ft. |
| | |
| Wellbore Completed | | Completion Date: | 7/23/2015 | | Spud Date: | 6/29/2015 | Spud Date Is: | ACTUAL | | Measured TD: | 13558 ft. | Measured PB depth: | 13550 ft. | | True Vertical TD: | 7081 ft. | True Vertical PB depth: | 7081 ft. | | Top PZ Location: | Sec:12 Twp: 5N 68W | Footage: 2331 FSL 12 FEL | | Bottom Hole Location: | Sec:11 Twp: 5N 68W | Footage: 2218 FSL 499 FEL | | Log Types: | CBL, LWD/GR, CNL, (IND in 05-069-06413, 05-069-06401, 05-069-06402) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16 in., Top: 0 ft., Depth: 56 ft., Weight: 42.1 , Citings Type: ACTUAL | | Cement: | Sacks: 36, Top: 0 ft., Bottom: 56 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1865 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 716, Top: 0 ft., Bottom: 1865 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.5 in., Size: 5.5 in., Top: 0 ft., Depth: 13534 ft., Weight: 17 , Citings Type: ACTUAL | | Cement: | Sacks: 1920, Top: 12 ft., Bottom: 13534 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4630 ft. | | | | | SHARON SPRINGS | 6986 ft. | | | | | NIOBRARA | 7042 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 3/1/2025 Interval Top: 7562 ft. Interval Bottom: 13433 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 11/25/2015 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 10/18/2015 | Treatment End Date: | 10/26/2015 | | Treatment Summary: | "PERF AND FRAC FROM 7562-13,433.
357 BBL ACID, 158,626 BBL SLICKWATER, 7,166 BBL WATER, - 166,149 BBL TOTAL FLUID
5,018,731# 40/70 GENOA/SAND HILLS, - 5,018,731# TOTAL SAND."
| | Total fluid used in treatment (bbls): | 166149 | Max pressure during treatment (psi): | 7650 | | Total gas used in treatment (mcf): | 0 | Fluid density (lbs/gal): | 8.30 | | Type Of gas: | | Number Of staged intervals: | 29 | | Total acid used in treatment (bbls): | 357 | Min frac gradient (psi/ft): | 0.88 | | Recycled water used in treatment (bbls): | 0 | Total flowback volume recovered (bbls): | 2545 | | Fresh water used in treatment (bbls): | 165792 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 5018731 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 12/6/2015 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 301 | | BBLS_OIL | 198 | | BTU_GAS | 1345 | | CALC_BBLS_H2O | 301 | | CALC_BBLS_OIL | 198 | | CALC_GOR | 1010 | | CALC_MCF_GAS | 200 | | CASING_PRESS | 900 | | GRAVITY_OIL | 46 | | MCF_GAS | 200 |
| | Perforation Data: | | Interval Top: | 7562 ft. | # Of Holes: | 708 | | Interval Bottom: | 13433 ft. | Hole Size: | 0.46 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 3937 |
| Total Gas Produced (MCF) | 8943 |
| GOR | 2271 |
| GOR Determination | BOE |
| Average BOE per Day | 14.891 |
| Average MCFE per Day | 86.400 |
| Federal Financial Assurance | i | |
|
|
