COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 This operator is no longer active in the State of Colorado.
 Surface Location
 API# 05-069-06310		Well Classification: ERIW Status: PR - 1/1/2024
Well Name/No:CHEYENNE RIDGE #7-1 (OWP)
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:PROSPECT ENERGY LLC - 10312
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date1/1/2024
FacilityID:217123LocationID:307200
County:LARIMER #069Location:SWSE 7 8N68W 6
Field:FORT COLLINS - #25100Elevation:5168 ft.
Basin:DENVER (DJ) BASIN
Planned Location:495FSL  1750 FELLat/Long: 40.669728 / -105.044624Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 40.669728 / -105.044624Lat/Long Source: Field Measured

FracFocus
Disclosure: Sidetrack #00
Start Date: 3/25/2011
End Date: 3/25/2011
Reported: 11/8/2011
Prior to rule 205A.b.(2)(A)
Days to report: 228
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: OW             Status: PR - 1/1/2024             Measured TD: 5250 ft.    Vertical TD: 5192 ft.

 Wellbore Data for Original WellboreWellbore Classification: OW        PR - 1/1/2024
Wellbore PermitDIRECTIONAL
Permit #: Expiration Date:12/16/2012
Proposed Top PZ Location:Sec:7 Twp: 8N 68W Footage: 358 FSL  1227 FEL
Bottom Hole Location:Sec:7 Twp: 8N 68W Footage: 352 FSL  1205 FEL
Proposed Depth/Form:5235 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: MDDYJ , Formation: MUDDY J , Order: 84 , Unit Acreage: 0, Drill Unit:
Formation And Spacing:Code: NBRR , Formation: NIOBRARA , Order: , Unit Acreage: , Drill Unit:
Wellbore Completed
Completion Date:9/19/1992
Spud Date:8/29/1992Spud Date Is:ACTUAL
Measured TD:5250 ft.Measured PB depth:5180 ft.
True Vertical TD:5192 ft.True Vertical PB depth:5123 ft.
Top PZ Location:Sec:7 Twp: 8N 68WFootage: 429 FSL  1393 FEL
Bottom Hole Location:Sec:7 Twp: 8N 68WFootage: 352 FSL  1205 FEL
Log Types:NO NEW LOGS RUN
Log Types:DIL, GR, DENSITY NEUTRON, DIRECTIONAL, CIBL
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 503 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 310, Top: 0 ft., Bottom: 503 ft., Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 5235 ft., Weight: 15.5 , Citings Type: ACTUAL
Cement:Sacks: 370, Top: 3214 ft., Bottom: 5235 ft., Determination Method: CBL
Additional Cement:String Type: 1ST , Top: 0 ft., Depth: 732 ft., Bottom: 732 ft., Sacks: 209, Method: 1 INCH
FormationInterval TopLog BottomCoredDSTs
HYGIENE0 ft.
NIOBRARA4214 ft.
TIMPAS4576 ft.
FORT HAYS4576 ft.
CODELL4599 ft.
BENTONITE4887 ft.
MUDDY5064 ft.
MUDDY J5122 ft.

Formation MDDYJ                   Formation Classification:  OW                   Status:  AB - 12/16/2010                Interval Top: 5122 ft.    Interval Bottom: 5172 ft.

 Completed Information for Formation MUDDY J
1st Production Date:9/24/1992Choke Size:
Formation Name:MUDDY JCommingled:
Production Method:
Open Hole Completion:
Formation Treatment
Treatment Date:9/19/1992
Treatment Summary:TREATED WITH 1000 GALLONS OF 3% HCl FROM 5160 TO 5172 FEET.
Tubing Size:2.375 in.Tubing Setting Depth:5045 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:N/ATest Method:
Hours Tested:Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 1307
TUBING_PRESS 860
Perforation Data:
Interval Top:5122 ft.# Of Holes:51
Interval Bottom:5172 ft.Hole Size:0.4 in.

Formation NBRR                     Formation Classification:  OW                     Status:  PR - 1/1/2024                  Interval Top: 4230 ft.    Interval Bottom: 4490 ft.

 Completed Information for Formation NIOBRARA
1st Production Date:3/25/2011Choke Size:
Formation Name:NIOBRARACommingled:
Production Method:
Open Hole Completion:
Formation Treatment
Treatment Date:3/25/2011
Treatment Summary:PERFORATION INTERVALS: 4230-4240 (30 HOLES); 4308-4324 (48 HOLES); 4354-4384 (90 HOLES); 4480-4490 (30 HOLES). PUMPED 24 BBLS 10% HCl, 30 BBLS LINEAR GEL, 3410 BBLS OF 22 LB XLINK GEL; 207 BBLS SLICKWATER; 36 BBLS FRESH WATER FLUSH; PROPPANT - 226,090 LBS OF 20/40 OTTAWA SAND AND 52,650 LBS 16/30 TEXAS GOLD SAND. 3707 BBLS TO RECOVER.
Tubing Size:2.375 in.Tubing Setting Depth:4547 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:4/4/2011Test Method:PUMPING
Hours Tested:24Gas Type:SHALE
Gas Disposal:FLARED
Test TypeMeasure
BBLS_H2O 46
BBLS_OIL 54
BTU_GAS 1229
CALC_BBLS_H2O 46
CALC_BBLS_OIL 54
CALC_GOR 12
CALC_MCF_GAS 66
CASING_PRESS 20
GRAVITY_OIL 33
MCF_GAS 66
TUBING_PRESS 40
Perforation Data:
Interval Top:4230 ft.# Of Holes:198
Interval Bottom:4490 ft.Hole Size:0.42 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
