COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-067-09169		Well Classification: LO Status: AL - 2/5/2015
Well Name/No:SOUTE FC 34-8 #26-4
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:RED WILLOW PRODUCTION COMPANY - 81295
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:750881003
Facility Status:ALStatus Date2/5/2015
FacilityID:284802LocationID:333964
County:LA PLATA #067Location:SESE 26 34N8W M
Field:IGNACIO BLANCO - #38300Elevation:6605 ft.
Basin:SAN JUAN BASIN
Planned Location:1020FSL  1075 FELLat/Long: 37.157640 / -107.681160Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification:              Status: AL - 2/5/2015             Measured TD:

 Wellbore Data for Original WellboreWellbore Classification:         AL - 2/5/2015
Wellbore PermitDIRECTIONAL
Permit #: Expiration Date:8/28/2015
Proposed Top PZ Location:Sec:26 Twp: 34N 8W Footage: 1938 FSL  1797 FEL
Bottom Hole Location:Sec:26 Twp: 34N 8W Footage: 2135 FSL  1952 FEL
Proposed Depth/Form:3413 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:INDIANSurface Owner:INDIAN
Unit: Unit Number:
Formation And Spacing:Code: FRLDC , Formation: FRUITLAND COAL , Order: 112-180 , Unit Acreage: 320, Drill Unit: E/2
Casing:String Type: CONDUCTOR, Hole Size: 12.25 in., Size: 8.625 in., Top: , Depth: 500 ft., Weight: 24 , Citings Type: PLANNED
Cement:Sacks: 390, Top: 0 ft., Bottom: 500 ft.
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 500 ft., Weight: 24 , Citings Type: PLANNED
Cement:Sacks: 390, Top: 0 ft., Bottom: 500 ft.
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 3413 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 610, Top: 0 ft., Bottom: 3413 ft.
Casing:String Type: 2ND, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 3413 ft., Weight: 17 , Citings Type: PLANNED
Cement:Sacks: 610, Top: , Bottom: 3413 ft.
Wellbore Completed
Completion Date:N/A
Measured TD:Measured PB depth:
True Vertical TD:True Vertical PB depth:
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i Yes
