Wellbore #00 Wellbore Classification: OW Status: PR - 6/1/2024 Measured TD: 17876 ft. Vertical TD: 7322 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 6/1/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | | Expiration Date: | 9/25/2019 | | Proposed Top PZ Location: | Sec:16 Twp: 7N 80W | Footage: 710 FNL 499 FWL | | Bottom Hole Location: | Sec:21 Twp: 7N 80W | Footage: 102 FSL 430 FWL | | Proposed Depth/Form: | 17909 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 531-52 , Unit Acreage: 1281, Drill Unit: W/2 Sec 4, 9, 16, 21 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 16.25 in., Top: 0 ft., Depth: 90 ft., Weight: 65 , Citings Type: PLANNED | | Cement: | Sacks: 189, Top: 0 ft., Bottom: 90 ft. | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2400 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 629, Top: 0 ft., Bottom: 2400 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 18016 ft., Weight: 20 , Citings Type: PLANNED | | Cement: | Sacks: 3007, Top: 0 ft., Bottom: 18016 ft. |
| | |
| Wellbore Completed | | Completion Date: | 3/18/2018 | | Spud Date: | 1/31/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 17876 ft. | Measured PB depth: | 17779 ft. | | True Vertical TD: | 7322 ft. | True Vertical PB depth: | 7333 ft. | | Top PZ Location: | Sec:16 Twp: 7N 80W | Footage: 710 FNL 499 FWL | | Bottom Hole Location: | Sec:21 Twp: 7N 80W | Footage: 102 FSL 430 FWL | | Log Types: | MWD, Mud, CBL, (partial Triple Combo in 057-06539) | | Casing: | String Type: CONDUCTOR, Hole Size: 20 in., Size: 16 in., Top: 0 ft., Depth: 115 ft., Weight: 133 , Citings Type: ACTUAL | | Cement: | Sacks: 72, Top: 0 ft., Bottom: 115 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2400 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 595, Top: 0 ft., Bottom: 2400 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 5.5 in., Top: 0 ft., Depth: 17876 ft., Weight: 20 , Citings Type: ACTUAL | | Cement: | Sacks: 3255, Top: 1850 ft., Bottom: 17876 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | LANCE | 3259 ft. | | | | | FOX HILLS | 3973 ft. | | | | | PIERRE | 4408 ft. | | | | | SUSSEX | 5400 ft. | | | | | SHANNON | 5903 ft. | | | | | MANCOS | 7073 ft. | | | | | NIOBRARA | 7373 ft. | | | |
Formation NBRR Formation Classification: OW Status: PR - 6/1/2024 Interval Top: 8199 ft. Interval Bottom: 17700 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 8/21/2018 | Choke Size: | | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 6/11/2018 | Treatment End Date: | 6/24/2018 | | Treatment Summary: | Plug & Perf Completion: 1,841 bbls of 15% NEFE HCL Acid, 234,902 bbls of fluid, and 1,295,378 lbs of 40/70 and 8,237,849 lbs of 20/40 proppant.
| | Total fluid used in treatment (bbls): | 236743 | Max pressure during treatment (psi): | 8157 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.33 | | Type Of gas: | | Number Of staged intervals: | 39 | | Total acid used in treatment (bbls): | 1841 | Min frac gradient (psi/ft): | 0.91 | | Recycled water used in treatment (bbls): | | Total flowback volume recovered (bbls): | 42947 | | Fresh water used in treatment (bbls): | 234902 | Disposition method For flowback: | DISPOSAL | | Total proppant used (lbs): | 9533227 | Green completions techniques utilized: | No | | Reason green techniques Not utilized: PIPELINE |
| | Tubing Size: | 2.875 in. | Tubing Setting Depth: | 7810 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 7/27/2018 | Test Method: | | | Hours Tested: | 24 | Gas Type: | WET | | Gas Disposal: | FLARED | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1660 | | BBLS_OIL | 1089 | | BTU_GAS | 1600 | | CALC_BBLS_H2O | 1660 | | CALC_BBLS_OIL | 1089 | | CALC_GOR | 698 | | CALC_MCF_GAS | 760 | | CASING_PRESS | 620 | | GRAVITY_OIL | 38 | | MCF_GAS | 760 | | TUBING_PRESS | 160 |
| | Perforation Data: | | Interval Top: | 8199 ft. | # Of Holes: | 1170 | | Interval Bottom: | 17700 ft. | Hole Size: | 0.42 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 2311 |
| Total Gas Produced (MCF) | 9309 |
| GOR | 4028 |
| GOR Determination | BOE |
| Average BOE per Day | 10.743 |
| Average MCFE per Day | 62.291 |
