Wellbore #00 Wellbore Classification: OW Status: PR - 4/1/2024 Measured TD: 12181 ft. Vertical TD: 7160 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 4/1/2024 | | Wellbore Permit | HORIZONTAL | | Permit #: | 20084612 | Expiration Date: | 8/27/2009 | | Proposed Top PZ Location: | Sec:8 Twp: 7N 80W | Footage: 654 FSL 697 FWL | | Bottom Hole Location: | Sec:8 Twp: 7N 80W | Footage: 693 FNL 1999 FWL | | Proposed Depth/Form: | 13056 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: NBRR , Formation: NIOBRARA , Order: 531-2 , Unit Acreage: 640, Drill Unit: ALL |
| | |
| Wellbore Completed | | Completion Date: | 10/31/2008 | | Spud Date: | 10/2/2008 | Spud Date Is: | ACTUAL | | Measured TD: | 12181 ft. | Measured PB depth: | 12050 ft. | | True Vertical TD: | 7160 ft. | True Vertical PB depth: | 7147 ft. | | Top PZ Location: | Sec:8 Twp: 7N 80W | Footage: 654 FSL 697 FWL | | Bottom Hole Location: | Sec:8 Twp: 7N 80W | Footage: 693 FNL 1999 FWL | | Log Types: | COMP.SONIC LOG, AIL, COMPACT QUAD QUICK LOOK LOG, FMI, CPDCNL, CBL, GR/CCL | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 60 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: , Top: 0 ft., Bottom: 60 ft., Determination Method: | | Casing: | String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1046 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 535, Top: 0 ft., Bottom: 1046 ft., Determination Method: | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: 0 ft., Depth: 7338 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 730, Top: 380 ft., Bottom: 7338 ft., Determination Method: CBL | | Casing: | String Type: 1ST LINER, Hole Size: 6.125 in., Size: 4.5 in., Top: 6647 ft., Depth: 12175 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 525, Top: 6646 ft., Bottom: 12175 ft., Determination Method: | | Formation | Interval Top | Log Bottom | Cored | DSTs | | SUSSEX | 4367 ft. | | N | N | | SHANNON | 5318 ft. | | N | N | | NIOBRARA | 6843 ft. | | N | N |
Formation NBRR Formation Classification: OW Status: PR - 4/1/2024 Interval Top: 8062 ft. Interval Bottom: 11920 ft.| Completed Information for Formation NIOBRARA | | 1st Production Date: | 12/21/2008 | Choke Size: | 0.375 in. | | Formation Name: | NIOBRARA | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 10/31/2008 | | Treatment Summary: | FRACTURE STIMULATED LATERAL FROM 7160' TO 12,181' |
| | Tubing Size: | 2.875 in. | Tubing Setting Depth: | 6617 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/20/2009 | Test Method: | | | Hours Tested: | 24 | Gas Type: | SHALE | | Gas Disposal: | FLARED | |
| Test Type | Measure |
|---|
| BBLS_H2O | 240 | | BBLS_OIL | 236 | | BTU_GAS | 1726 | | CALC_BBLS_OIL | 236 | | CALC_GOR | 1008 | | CALC_MCF_GAS | 238 | | GRAVITY_OIL | 38 | | MCF_GAS | 238 |
| | Perforation Data: | | Interval Top: | 8062 ft. | # Of Holes: | 480 | | Interval Bottom: | 11920 ft. | Hole Size: | 0.38 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 3721 |
| Total Gas Produced (MCF) | 1989 |
| GOR | 534 |
| GOR Determination | BOE |
| Average BOE per Day | 11.149 |
| Average MCFE per Day | 64.659 |
| Federal Financial Assurance | i | |
|
|
