Wellbore #00 Wellbore Classification: Status: PR - 9/1/2022 Measured TD: | Wellbore Data for Original Wellbore | Wellbore Classification: PR - 9/1/2022 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 5/2/2025 | | Proposed Top PZ Location: | Sec:35 Twp: 4S 96W | Footage: 384 FSL 1492 FEL | | Bottom Hole Location: | Sec:35 Twp: 4S 96W | Footage: 350 FSL 1586 FEL | | Proposed Depth/Form: | 12186 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEE | | Unit: | Big Jimmy Unit | Unit Number: | COC074105X | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 1-229 , Unit Acreage: , Drill Unit: | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: 0 ft., Depth: 100 ft., Weight: 54# , Citings Type: PLANNED | | Cement: | Sacks: 218, Top: 0 ft., Bottom: 100 ft. | | Casing: | String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: 0 ft., Depth: 3000 ft., Weight: 36# , Citings Type: PLANNED | | Cement: | Sacks: 710, Top: 0 ft., Bottom: 3000 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 12186 ft., Weight: 11.6# , Citings Type: PLANNED | | Cement: | Sacks: 1465, Top: 3000 ft., Bottom: 12186 ft. |
| | |
| Wellbore Completed | | Completion Date: | N/A | | Spud Date: | 5/30/2022 | Spud Date Is: | NOTICE | | Measured TD: | | Measured PB depth: | | | True Vertical TD: | | True Vertical PB depth: | | | No formation data to display. |
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 151 |
| Total Gas Produced (MCF) | 236617 |
| GOR | 1567000 |
| GOR Determination | MCFE |
| Average BOE per Day | 112.206 |
| Average MCFE per Day | 650.836 |
| Federal Financial Assurance | i | Y |
|
|
