Wellbore #00 Wellbore Classification: GW Status: PR - 3/16/2020 Measured TD: 9231 ft. Vertical TD: 8983 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 3/16/2020 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 8/30/2020 | | Proposed Top PZ Location: | Sec:8 Twp: 6S 94W | Footage: 1070 FSL 658 FWL | | Bottom Hole Location: | Sec:8 Twp: 6S 94W | Footage: 1070 FSL 658 FWL | | Proposed Depth/Form: | 9272 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEDERAL | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 139-40 , Unit Acreage: , Drill Unit: | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 80 ft., Weight: 47.4 , Citings Type: PLANNED | | Cement: | Sacks: 134, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1100 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 266, Top: 0 ft., Bottom: 1100 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 9272 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1124, Top: 4649 ft., Bottom: 9272 ft. |
| | |
| Wellbore Completed | | Completion Date: | 7/19/2019 | | Spud Date: | 7/15/2019 | Spud Date Is: | ACTUAL | | Measured TD: | 9231 ft. | Measured PB depth: | 9192 ft. | | True Vertical TD: | 8983 ft. | True Vertical PB depth: | 8944 ft. | | Top PZ Location: | Sec:8 Twp: 6S 94W | Footage: 1060 FSL 655 FWL | | Bottom Hole Location: | Sec:8 Twp: 6S 94W | Footage: 1062 FSL 620 FWL | | Log Types: | CBL, NEU, (Triple Combo in API 045-24035) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 80 ft., Weight: 47.44 , Citings Type: ACTUAL | | Cement: | Sacks: 134, Top: 0 ft., Bottom: 80 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1142 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 300, Top: 0 ft., Bottom: 1142 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 9221 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 1605, Top: 740 ft., Bottom: 9231 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 2848 ft. | | | | | WASATCH | 4747 ft. | | | | | MESAVERDE | 5443 ft. | | | | | OHIO CREEK | 5443 ft. | | | | | WILLIAMS FORK | 5535 ft. | | | | | CAMEO | 8236 ft. | | | | | ROLLINS | 9118 ft. | | | |
Formation WFCM Formation Classification: OG Status: PR - 3/16/2020 Interval Top: 6437 ft. Interval Bottom: 9048 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 11/18/2019 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 9/24/2019 | Treatment End Date: | 10/3/2019 | | Treatment Summary: | 116366 bbls of Slickwater: 3743 gals of Biocide | | Total fluid used in treatment (bbls): | 116455 | Max pressure during treatment (psi): | 8042 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 15 | | Total acid used in treatment (bbls): | 0 | Min frac gradient (psi/ft): | 0.73 | | Recycled water used in treatment (bbls): | 116366 | Total flowback volume recovered (bbls): | 48809 | | Fresh water used in treatment (bbls): | 89 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | 0 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | N/A | Test Method: | | | Hours Tested: | | Gas Type: | | | Gas Disposal: | | |
| Test Type | Measure |
|---|
| BTU_GAS | 1084 | | CALC_MCF_GAS | 1299 | | CASING_PRESS | 1982 | | MCF_GAS | 1299 | | TUBING_PRESS | 1491 |
| | Perforation Data: | | Interval Top: | 6437 ft. | # Of Holes: | 315 | | Interval Bottom: | 9048 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 229 |
| Total Gas Produced (MCF) | 94687 |
| GOR | 413480 |
| GOR Determination | MCFE |
| Average BOE per Day | 45.364 |
| Average MCFE per Day | 263.115 |
| Federal Financial Assurance | i | Y |
|
|
