Wellbore #00 Wellbore Classification: GW Status: PR - 10/16/2018 Measured TD: 8484 ft. Vertical TD: 8249 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 10/16/2018 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 9/26/2019 | | Proposed Top PZ Location: | Sec:26 Twp: 6S 95W | Footage: 857 FSL 2052 FEL | | Bottom Hole Location: | Sec:26 Twp: 6S 95W | Footage: 857 FSL 2052 FEL | | Proposed Depth/Form: | 8501 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEDERAL | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 440-79 , Unit Acreage: , Drill Unit: | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 80 ft., Weight: 47.4 , Citings Type: PLANNED | | Cement: | Sacks: 134, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1100 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 266, Top: 0 ft., Bottom: 1100 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 8501 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1149, Top: 2225 ft., Bottom: 8501 ft. |
| | |
| Wellbore Completed | | Completion Date: | 8/20/2018 | | Spud Date: | 8/15/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 8484 ft. | Measured PB depth: | 8441 ft. | | True Vertical TD: | 8249 ft. | True Vertical PB depth: | 8206 ft. | | Top PZ Location: | Sec:26 Twp: 6S 95W | Footage: 899 FSL 2050 FEL | | Bottom Hole Location: | Sec:26 Twp: 6S 95W | Footage: 841 FSL 2052 FEL | | Log Types: | CBL, PULSED NEUTRON (TRIPLE COMBO IN 045-23709) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 104 ft., Weight: 47.44 , Citings Type: ACTUAL | | Cement: | Sacks: 174, Top: 0 ft., Bottom: 104 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1128 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 300, Top: 0 ft., Bottom: 1128 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 8474 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 1835, Top: 1247 ft., Bottom: 8484 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 2508 ft. | | | | | WILLIAMS FORK | 4787 ft. | | | | | MESAVERDE | 4879 ft. | | | | | OHIO CREEK | 4879 ft. | | | | | CAMEO | 7973 ft. | | | | | ROLLINS | 8367 ft. | | | |
Formation WFCM Formation Classification: GW Status: PR - 10/16/2018 Interval Top: 5828 ft. Interval Bottom: 8299 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 10/16/2018 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 9/20/2018 | Treatment End Date: | 9/26/2018 | | Treatment Summary: | 68157 bbls of slickwater; 1234424 100/Mesh; 1727 gals of biocide | | Total fluid used in treatment (bbls): | 68198 | Max pressure during treatment (psi): | 7678 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 12 | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | 0.77 | | Recycled water used in treatment (bbls): | 68157 | Total flowback volume recovered (bbls): | 22949 | | Fresh water used in treatment (bbls): | 41 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | 1234424 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8052 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 10/16/2018 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1058 | | CALC_MCF_GAS | 3303 | | CASING_PRESS | 1530 | | MCF_GAS | 3303 | | TUBING_PRESS | 1190 |
| | Perforation Data: | | Interval Top: | 5828 ft. | # Of Holes: | 264 | | Interval Bottom: | 8299 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 80 |
| Total Gas Produced (MCF) | 34306 |
| GOR | 428825 |
| GOR Determination | MCFE |
| Average BOE per Day | 16.432 |
| Average MCFE per Day | 95.287 |
| Federal Financial Assurance | i | Y |
|
|
