Wellbore #00 Wellbore Classification: GW Status: PR - 9/3/2018 Measured TD: 9565 ft. Vertical TD: 8489 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 9/3/2018 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 9/26/2019 | | Proposed Top PZ Location: | Sec:26 Twp: 6S 95W | Footage: 167 FNL 730 FWL | | Bottom Hole Location: | Sec:26 Twp: 6S 95W | Footage: 167 FNL 730 FWL | | Proposed Depth/Form: | 9595 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEDERAL | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 440-25 , Unit Acreage: 320, Drill Unit: W2 Sec 26 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 80 ft., Weight: 47.4 , Citings Type: PLANNED | | Cement: | Sacks: 134, Top: 0 ft., Bottom: 80 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1100 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 266, Top: 0 ft., Bottom: 1100 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 9595 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1213, Top: 2954 ft., Bottom: 9595 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/31/2018 | | Spud Date: | 5/26/2018 | Spud Date Is: | ACTUAL | | Measured TD: | 9565 ft. | Measured PB depth: | 9522 ft. | | True Vertical TD: | 8489 ft. | True Vertical PB depth: | 8446 ft. | | Top PZ Location: | Sec:26 Twp: 6S 95W | Footage: 264 FNL 803 FWL | | Bottom Hole Location: | Sec:26 Twp: 6S 95W | Footage: 146 FNL 730 FWL | | Log Types: | CBL, PULSED NEUTRON (TRIPLE COMBO IN API 045-23709) | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 104 ft., Weight: 47.44 , Citings Type: ACTUAL | | Cement: | Sacks: 174, Top: 0 ft., Bottom: 104 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1124 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 300, Top: 0 ft., Bottom: 1124 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 9555 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 1940, Top: 1958 ft., Bottom: 9565 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 5203 ft. | | | | | WILLIAMS FORK | 5743 ft. | | | | | MESAVERDE | 5800 ft. | | | | | OHIO CREEK | 5800 ft. | | | | | CAMEO | 9027 ft. | | | | | ROLLINS | 9356 ft. | | | |
Formation WFCM Formation Classification: GW Status: PR - 9/3/2018 Interval Top: 6961 ft. Interval Bottom: 9296 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 9/3/2018 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 8/1/2018 | Treatment End Date: | 8/9/2018 | | Treatment Summary: | 63638 bbls of slickwater; 1767266 100/Mesh; 2372 gals of biocide | | Total fluid used in treatment (bbls): | 63694 | Max pressure during treatment (psi): | 8591 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 11 | | Total acid used in treatment (bbls): | | Min frac gradient (psi/ft): | 0.76 | | Recycled water used in treatment (bbls): | 63638 | Total flowback volume recovered (bbls): | 32914 | | Fresh water used in treatment (bbls): | 56 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | 1767266 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 9076 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 9/3/2018 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1118 | | CALC_MCF_GAS | 2009 | | CASING_PRESS | 2124 | | MCF_GAS | 2009 | | TUBING_PRESS | 1640 |
| | Perforation Data: | | Interval Top: | 6961 ft. | # Of Holes: | 264 | | Interval Bottom: | 9296 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 201 |
| Total Gas Produced (MCF) | 73027 |
| GOR | 363318 |
| GOR Determination | MCFE |
| Average BOE per Day | 35.067 |
| Average MCFE per Day | 203.399 |
| Federal Financial Assurance | i | Y |
|
|
