Wellbore #00 Wellbore Classification: GW Status: PR - 3/25/2016 Measured TD: 10834 ft. Vertical TD: 9907 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 3/25/2016 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 1/14/2017 | | Proposed Top PZ Location: | Sec:8 Twp: 7S 93W | Footage: 2531 FNL 474 FEL | | Bottom Hole Location: | Sec:8 Twp: 7S 93W | Footage: 2531 FNL 474 FEL | | Proposed Depth/Form: | 10668 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEDERAL | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 139-76 , Unit Acreage: 480, Drill Unit: Sec 8E2, N2NW,S2SW | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 60 ft., Weight: 48# , Citings Type: PLANNED | | Cement: | Sacks: 25, Top: 0 ft., Bottom: 60 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1300 ft., Weight: 32.3# , Citings Type: PLANNED | | Cement: | Sacks: 340, Top: 0 ft., Bottom: 1300 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 10874 ft., Weight: 11.6# , Citings Type: PLANNED | | Cement: | Sacks: 831, Top: 7610 ft., Bottom: 10874 ft. |
| | |
| Wellbore Completed | | Completion Date: | 1/12/2016 | | Spud Date: | 1/6/2016 | Spud Date Is: | ACTUAL | | Measured TD: | 10834 ft. | Measured PB depth: | 10792 ft. | | True Vertical TD: | 9907 ft. | True Vertical PB depth: | 9865 ft. | | Top PZ Location: | Sec:8 Twp: 7S 93W | Footage: 2493 FNL 472 FEL | | Bottom Hole Location: | Sec:8 Twp: 7S 93W | Footage: 2533 FNL 488 FEL | | Log Types: | RPM/MUD/CBL/Triple Combo on 045-22773 | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 42 ft., Weight: 47.4 , Citings Type: ACTUAL | | Cement: | Sacks: 16, Top: 0 ft., Bottom: 42 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1311 ft., Weight: 32.3 , Citings Type: ACTUAL | | Cement: | Sacks: 345, Top: 0 ft., Bottom: 1311 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 10824 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 1085, Top: 5557 ft., Bottom: 10824 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 4217 ft. | | | | | MESAVERDE | 7068 ft. | | | | | WILLIAMS FORK | 7068 ft. | | | | | CAMEO | 9894 ft. | | | | | ROLLINS | 10687 ft. | | | |
Formation WFCM Formation Classification: GW Status: PR - 3/25/2016 Interval Top: 8309 ft. Interval Bottom: 10658 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 2/15/2016 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 2/15/2016 | Treatment End Date: | 3/14/2016 | | Treatment Summary: | 1500 Gals 7.5% HCL; 91892 BBLs Slickwater; 842980 40/70 Sand; 881895 100/mesh;
| | Total fluid used in treatment (bbls): | 91928 | Max pressure during treatment (psi): | 5046 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.43 | | Type Of gas: | | Number Of staged intervals: | 11 | | Total acid used in treatment (bbls): | 36 | Min frac gradient (psi/ft): | 0.60 | | Recycled water used in treatment (bbls): | 91892 | Total flowback volume recovered (bbls): | 30165 | | Fresh water used in treatment (bbls): | | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | 1724875 | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 10448 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/25/2016 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1112 | | CALC_MCF_GAS | 1700 | | CASING_PRESS | 2150 | | MCF_GAS | 1700 | | TUBING_PRESS | 1425 |
| | Perforation Data: | | Interval Top: | 8309 ft. | # Of Holes: | 264 | | Interval Bottom: | 10658 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 112 |
| Total Gas Produced (MCF) | 78287 |
| GOR | 698991 |
| GOR Determination | MCFE |
| Average BOE per Day | 37.294 |
| Average MCFE per Day | 216.303 |
| Federal Financial Assurance | i | Y |
|
|
