Wellbore #00 Wellbore Classification: GW Status: PR - 8/1/2019 Measured TD: 12110 ft. Vertical TD: 11271 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 8/1/2019 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 2/21/2015 | | Proposed Top PZ Location: | Sec:34 Twp: 4S 96W | Footage: 170 FSL 573 FWL | | Bottom Hole Location: | Sec:34 Twp: 4S 96W | Footage: 170 FSL 573 FWL | | Proposed Depth/Form: | 12801 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEE | | Unit: | BIG JIMMY UNIT | Unit Number: | COC74105X | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-13 , Unit Acreage: , Drill Unit: | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: 0 ft., Depth: 148 ft., Weight: 52.8# , Citings Type: PLANNED | | Cement: | Sacks: 130, Top: 0 ft., Bottom: 148 ft. | | Casing: | String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: 0 ft., Depth: 2966 ft., Weight: 36# , Citings Type: PLANNED | | Cement: | Sacks: 1150, Top: 0 ft., Bottom: 2966 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 12247 ft., Weight: 11.6# , Citings Type: PLANNED | | Cement: | Sacks: 1137, Top: 5873 ft., Bottom: 12247 ft. |
| | |
| Wellbore Completed | | Completion Date: | 4/3/2019 | | Spud Date: | 10/16/2013 | Spud Date Is: | ACTUAL | | Measured TD: | 12110 ft. | Measured PB depth: | 12042 ft. | | True Vertical TD: | 11271 ft. | True Vertical PB depth: | 11203 ft. | | Top PZ Location: | Sec:34 Twp: 4S 96W | Footage: 215 FSL 631 FWL | | Bottom Hole Location: | Sec:34 Twp: 4S 96W | Footage: 163 FSL 447 FWL | | Log Types: | No logs ran | | Log Types: | CBL, Pulsed Neutron, (Triple Combo on 045-21909). | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: 0 ft., Depth: 148 ft., Weight: 52.8 , Citings Type: ACTUAL | | Cement: | Sacks: 130, Top: 0 ft., Bottom: 148 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: 0 ft., Depth: 2966 ft., Weight: 36 , Citings Type: ACTUAL | | Cement: | Sacks: 1150, Top: 0 ft., Bottom: 2966 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 12087 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 1807, Top: 3110 ft., Bottom: 12110 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | GREEN RIVER | 0 ft. | | N | N | | WASATCH | 3155 ft. | | N | N | | WASATCH G | 5888 ft. | | N | N | | FORT UNION | 6304 ft. | | N | N | | OHIO CREEK | 8405 ft. | | N | N | | WILLIAMS FORK | 8678 ft. | | N | N | | CAMEO | 11325 ft. | | N | N | | ROLLINS | 11953 ft. | | N | N |
Formation WFOCCM Formation Classification: GW Status: PR - 8/19/2019 Interval Top: 8422 ft. Interval Bottom: 11581 ft.| Completed Information for Formation WILLIAMS FORK-OHIO CREEK-CAMEO | | 1st Production Date: | 8/19/2019 | Choke Size: | | | Formation Name: | WILLIAMS FORK-OHIO CREEK-CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Type: | FRACTURE STIMULATION | | Treatment Date: | 7/30/2019 | Treatment End Date: | 8/12/2019 | | Treatment Summary: | 12-stage plug-and-perf completion;
250716 total bbls fluid pumped: 68584 bbls fresh water (slickwater), 181989 bbls recycled water (slickwater), and 143 bbls 7.5% HCl acid;
no proppant used. | | Total fluid used in treatment (bbls): | 250716 | Max pressure during treatment (psi): | 8473 | | Total gas used in treatment (mcf): | | Fluid density (lbs/gal): | 8.41 | | Type Of gas: | | Number Of staged intervals: | 12 | | Total acid used in treatment (bbls): | 143 | Min frac gradient (psi/ft): | 0.56 | | Recycled water used in treatment (bbls): | 181989 | Total flowback volume recovered (bbls): | 159109 | | Fresh water used in treatment (bbls): | 68584 | Disposition method For flowback: | RECYCLE | | Total proppant used (lbs): | | Green completions techniques utilized: | Yes | | Reason green techniques Not utilized: |
| | Tubing Size: | | Tubing Setting Depth: | | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 8/19/2019 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1200 | | BTU_GAS | 1050 | | CALC_BBLS_H2O | 1200 | | CALC_MCF_GAS | 38 | | CASING_PRESS | 2990 | | MCF_GAS | 38 |
| | Perforation Data: | | Interval Top: | 8422 ft. | # Of Holes: | 324 | | Interval Bottom: | 11581 ft. | Hole Size: | 0.37 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 86 |
| Total Gas Produced (MCF) | 46977 |
| GOR | 546244 |
| GOR Determination | MCFE |
| Average BOE per Day | 22.415 |
| Average MCFE per Day | 130.035 |
| Federal Financial Assurance | i | Y |
|
|
