Wellbore #00 Wellbore Classification: GW Status: PR - 5/1/2012 Measured TD: 7985 ft. Vertical TD: 7916 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 5/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 9/7/2013 | | Proposed Top PZ Location: | Sec:32 Twp: 6S 94W | Footage: 423 FNL 1845 FWL | | Bottom Hole Location: | Sec:32 Twp: 6S 94W | Footage: 423 FNL 1848 FWL | | Proposed Depth/Form: | 8052 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 139-64 , Unit Acreage: 320, Drill Unit: N/2 Fee Pooled | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 45 ft., Weight: 48 , Citings Type: PLANNED | | Cement: | Sacks: 50, Top: 0 ft., Bottom: 45 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1110 ft., Weight: 32.3 , Citings Type: PLANNED | | Cement: | Sacks: 293, Top: 0 ft., Bottom: 1110 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 8052 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 678, Top: 4132 ft., Bottom: 8052 ft. |
| | |
| Wellbore Completed | | Completion Date: | 12/5/2011 | | Spud Date: | 11/27/2011 | Spud Date Is: | ACTUAL | | Measured TD: | 7985 ft. | Measured PB depth: | 7944 ft. | | True Vertical TD: | 7916 ft. | True Vertical PB depth: | 7875 ft. | | Top PZ Location: | Sec:32 Twp: 6S 94W | Footage: 400 FNL 1849 FWL | | Bottom Hole Location: | Sec:32 Twp: 6S 94W | Footage: 418 FNL 1843 FWL | | Log Types: | SP/GR/HDIL/ZDL/CN/CBL and MUDLOGS | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 60 ft., Weight: 48 , Citings Type: ACTUAL | | Cement: | Sacks: 23, Top: 0 ft., Bottom: 60 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1145 ft., Weight: 32.3 , Citings Type: ACTUAL | | Cement: | Sacks: 320, Top: 0 ft., Bottom: 1145 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 7973 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 1370, Top: 2725 ft., Bottom: 7973 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 2047 ft. | | | | | MESAVERDE | 4395 ft. | | | | | CAMEO | 6944 ft. | | | | | ROLLINS | 7876 ft. | | | |
Formation WFCM Formation Classification: OW Status: PR - 4/29/2012 Interval Top: 5840 ft. Interval Bottom: 7752 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 3/22/2012 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 3/20/2012 | | Treatment Summary: | 3472 Gals 7 ½% HCL; 537700 # 30/50 Sand; 260500 100/Mesh; 21467 Bbls Slickwater (Summary) |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7543 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/29/2012 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1047 | | CALC_MCF_GAS | 1126 | | CASING_PRESS | 2539 | | MCF_GAS | 1126 | | TUBING_PRESS | 2362 |
| | Perforation Data: | | Interval Top: | 5840 ft. | # Of Holes: | 126 | | Interval Bottom: | 7752 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 45 |
| Total Gas Produced (MCF) | 22096 |
| GOR | 491022 |
| GOR Determination | MCFE |
| Average BOE per Day | 10.561 |
| Average MCFE per Day | 61.257 |
| Federal Financial Assurance | i | |
|
|
