Wellbore #00 Wellbore Classification: GW Status: PR - 5/1/2012 Measured TD: 7400 ft. Vertical TD: 7056 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 5/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 8/3/2012 | | Proposed Top PZ Location: | Sec:27 Twp: 6S 96W | Footage: 1805 FSL 939 FWL | | Bottom Hole Location: | Sec:27 Twp: 6S 96W | Footage: 1805 FSL 939 FWL | | Proposed Depth/Form: | 7424 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEDERAL | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 479-17 , Unit Acreage: 320, Drill Unit: S/2 | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: , Depth: 45 ft., Weight: 48# , Citings Type: PLANNED | | Cement: | Sacks: 25, Top: 0 ft., Bottom: 45 ft. | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: , Depth: 1872 ft., Weight: 32.3# , Citings Type: PLANNED | | Cement: | Sacks: 655, Top: 0 ft., Bottom: 1872 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: , Depth: 7424 ft., Weight: 11.6# , Citings Type: PLANNED | | Cement: | Sacks: 555, Top: , Bottom: 7424 ft. |
| | |
| Wellbore Completed | | Completion Date: | 5/19/2011 | | Spud Date: | 5/13/2011 | Spud Date Is: | ACTUAL | | Measured TD: | 7400 ft. | Measured PB depth: | 7358 ft. | | True Vertical TD: | 7056 ft. | True Vertical PB depth: | 7014 ft. | | Top PZ Location: | Sec:27 Twp: 6s 96w | Footage: 1805 FSL 948 FWL | | Bottom Hole Location: | Sec:27 Twp: 6s 96w | Footage: 1792 FSL 949 FWL | | Log Types: | CBL and Reservoir Performance Monitor (RPM), Mud | | Casing: | String Type: CONDUCTOR, Hole Size: 26 in., Size: 18 in., Top: 0 ft., Depth: 41 ft., Weight: 48 , Citings Type: ACTUAL | | Cement: | Sacks: 16, Top: 0 ft., Bottom: 41 ft., Determination Method: CALC | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2022 ft., Weight: 32.3 , Citings Type: ACTUAL | | Cement: | Sacks: 455, Top: 0 ft., Bottom: 2022 ft., Determination Method: CALC | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7388 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 990, Top: 3010 ft., Bottom: 7388 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 2156 ft. | | | | | MESAVERDE | 4084 ft. | | | | | CAMEO | 6782 ft. | | | | | ROLLINS | 7182 ft. | | | |
Formation WFCM Formation Classification: GW Status: PR - 8/31/2011 Interval Top: 5388 ft. Interval Bottom: 7145 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 7/29/2011 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 7/25/2011 | | Treatment Summary: | 3002 Gals 7 1/2% HCL; 1012800# 30/50 Sand; 27727 Bbls Slickwater;(Summary) |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6888 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 8/31/2011 | Test Method: | flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1034 | | CALC_MCF_GAS | 1443 | | CASING_PRESS | 1892 | | MCF_GAS | 1443 | | TUBING_PRESS | 1703 |
| | Perforation Data: | | Interval Top: | 5388 ft. | # Of Holes: | 121 | | Interval Bottom: | 7145 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 56 |
| Total Gas Produced (MCF) | 33087 |
| GOR | 590839 |
| GOR Determination | MCFE |
| Average BOE per Day | 15.780 |
| Average MCFE per Day | 91.532 |
| Federal Financial Assurance | i | Y |
|
|
