COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-18419		Well Classification: GW Status: PR - 1/11/2010
Well Name/No:FEDERAL #SG 534-23
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:TEP ROCKY MOUNTAIN LLC - 96850
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date1/11/2010
FacilityID:412012LocationID:335042
County:GARFIELD #045Location:NENE 26 7S96W 6
Field:GRAND VALLEY - #31290Elevation:5243 ft.
Basin:PICEANCE BASIN
Planned Location:1113FNL  625 FELLat/Long: 39.412478 / -108.069528Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.412479 / -108.069528Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: AB - 7/13/2009             Measured TD: 5515 ft.    Vertical TD: 5028 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        AB - 7/13/2009
Wellbore PermitDIRECTIONAL
Permit #:20090894 Expiration Date:4/28/2010
Proposed Top PZ Location:Sec: Twp: Footage: 132 FSL  1923 FEL
Bottom Hole Location:Sec:23 Twp: 7S 96W Footage: 132 FNL  1923 FEL
Proposed Depth/Form:5490 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEDERAL
Unit: Unit Number:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: 510-14 , Unit Acreage: 160, Drill Unit: SE4
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: , Depth: 5967 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: , Top: , Bottom:
Wellbore Completed
Completion Date:7/13/2009
Spud Date:7/6/2009Spud Date Is:ACTUAL
Measured TD:5515 ft.Measured PB depth:4902 ft.
True Vertical TD:5028 ft.True Vertical PB depth:4416 ft.
Bottom Hole Location:Sec: Twp: Footage:  FL   FL
Log Types:NONE
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 45 ft., Weight: 48 , Citings Type: ACTUAL
Cement:Sacks: 0, Top: 0 ft., Bottom: 45 ft., Determination Method:
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1243 ft., Weight: 32.3 , Citings Type: ACTUAL
Cement:Sacks: 360, Top: 0 ft., Bottom: 1243 ft., Determination Method:
  No formation data to display.

Sidetrack #01             Wellbore Classification: GW             Status: PR - 1/11/2010             Measured TD: 6005 ft.    Vertical TD: 5779 ft.

 Wellbore Data for Sidetrack #01Wellbore Classification: GW        PR - 1/11/2010
Wellbore PermitDIRECTIONAL
Permit #:20092853 Expiration Date:7/23/2011
Proposed Top PZ Location:Sec: Twp: Footage: 132 FSL  1923 FEL
Bottom Hole Location:Sec:23 Twp: 7S 96W Footage: 132 FSL  1923 FEL
Proposed Depth/Form:5967 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEDERAL
Unit: Unit Number:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: 510-14 , Unit Acreage: 160, Drill Unit: SE4
Wellbore Completed
Completion Date:7/19/2009
Spud Date:7/6/2009Spud Date Is:ACTUAL
Measured TD:6005 ft.Measured PB depth:5946 ft.
True Vertical TD:5779 ft.True Vertical PB depth:5720 ft.
Top PZ Location:Sec:23 Twp: 7S 96WFootage: 169 FSL  1897 FEL
Bottom Hole Location:Sec:23 Twp: 7S 96WFootage: 169 FSL  1897 FEL
Log Types:BOND, MUD, RPM
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 63 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: 0 ft., Bottom: 63 ft., Determination Method:
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1243 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 570, Top: 0 ft., Bottom: 1243 ft., Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 5982 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 710, Top: 3130 ft., Bottom: 5982 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WASATCH G921 ft.NN
MESAVERDE2913 ft.NN
CAMEO5370 ft.NN
ROLLINS5863 ft.NN

Formation WFCM                     Formation Classification:  GW                     Status:  PR - 3/1/2011                  Interval Top: 4400 ft.    Interval Bottom: 5915 ft.

 Completed Information for Formation WILLIAMS FORK - CAMEO
1st Production Date:9/11/2009Choke Size:0.188 in.
Formation Name:WILLIAMS FORK - CAMEOCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:9/11/2009
Treatment Summary:2000 GALS 7.5% HCL; 680700# 30/50 SAND; 14905 BBLS SLICKWATER
Tubing Size:2.375 in.Tubing Setting Depth:5610 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:10/20/2009Test Method:FLOWING
Hours Tested:21Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BTU_GAS 1082
CASING_PRESS 1386
MCF_GAS 909
TUBING_PRESS 1276
Perforation Data:
Interval Top:4400 ft.# Of Holes:90
Interval Bottom:5915 ft.Hole Size:0.35 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)13
Total Gas Produced (MCF)11453
GOR881000
GOR DeterminationMCFE
Average BOE per Day5.449
Average MCFE per Day31.573

 Federal Financial Assurance  i Y

 Tribal Well  i No
