 Surface Location
 API# 05-045-18322		Well Classification: GW Status: PR - 2/1/2026
Well Name/No:GMU #22-11B(522NW)
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:COC54736
Facility Status:PRStatus Date2/1/2026
FacilityID:301914LocationID:383334
County:GARFIELD #045Location:NESW 22 6S93W 6
Field:MAMM CREEK - #52500Elevation:6218 ft.
Basin:PICEANCE BASIN
Planned Location:1459FSL  2286 FWLLat/Long: 39.508556 / -107.763033Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.508579 / -107.763047Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 2/1/2026             Measured TD: 10057 ft.    Vertical TD: 9959 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 2/1/2026
Wellbore PermitDIRECTIONAL
Permit #:20090162 Expiration Date:3/8/2010
Proposed Top PZ Location:Sec: Twp: Footage: 2640 FNL  1970 FWL
Bottom Hole Location:Sec:22 Twp: 6S 93W Footage: 2640 FNL  1970 FWL
Proposed Depth/Form:9125 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEDERALSurface Owner:FEDERAL
Unit:GRASS MESA Unit Number:COC56608
Formation And Spacing:Code: ILES , Formation: ILES , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: , Depth: 40 ft., Weight: LINEPIPE , Citings Type: PLANNED
Cement:Sacks: 5, Top: 0 ft., Bottom: 40 ft.
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: , Depth: 924 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 248, Top: 0 ft., Bottom: 924 ft.
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 9238 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: 1094, Top: 500 ft., Bottom: 9238 ft.
Wellbore Completed
Completion Date:3/18/2010
Spud Date:2/18/2010Spud Date Is:ACTUAL
Measured TD:10057 ft.Measured PB depth:9989 ft.
True Vertical TD:9959 ft.True Vertical PB depth:9891 ft.
Top PZ Location:Sec: Twp: Footage: 2538 FSL  1979 FWL
Bottom Hole Location:Sec:22 Twp: 6S 93WFootage: 2540 FSL  1980 FWL
Log Types:RST, CBL AND PEX
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 62 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: 0 ft., Bottom: 0 ft., Determination Method: CALC
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1145 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 376, Top: 0 ft., Bottom: 1145 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: 0 ft., Depth: 10033 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 1002, Top: 3940 ft., Bottom: 10033 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WILLIAMS FORK5177 ft.7030 ft.
ROLLINS8926 ft.9483 ft.
COZZETTE9484 ft.9768 ft.
CORCORAN9769 ft.10057 ft.

Formation CRCRN                   Formation Classification:  GW                   Status:  PR - 1/1/2019                  Interval Top: 9774 ft.    Interval Bottom: 9885 ft.

 Completed Information for Formation CORCORAN
1st Production Date:7/11/2010Choke Size:
Formation Name:CORCORANCommingled:Yes
Production Method:
Open Hole Completion:
Formation Treatment
Treatment Date:6/28/2010
Treatment Summary:STAGES 1 TREATED WITH A TOTAL OF: 10,677 BBLS OF SLICKWATER, 112,000 LBS 20-40 SAND.
Tubing Size:2.375 in.Tubing Setting Depth:9359 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:7/28/2010Test Method:FLOWING
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 670
BTU_GAS 1170
CALC_BBLS_H2O 670
CALC_MCF_GAS 1033
CASING_PRESS 2600
MCF_GAS 1033
TUBING_PRESS 1400
Perforation Data:
Interval Top:9774 ft.# Of Holes:27
Interval Bottom:9885 ft.Hole Size:0.34 in.

Formation COZZ                     Formation Classification:  GW                     Status:  SI - 1/1/2011                  Interval Top: 9490 ft.    Interval Bottom: 9651 ft.

 Completed Information for Formation COZZETTE
1st Production Date:7/11/2010Choke Size:
Formation Name:COZZETTECommingled:
Production Method:
Open Hole Completion:
Formation Treatment
Treatment Date:6/29/2010
Treatment Summary:STAGES 2 TREATED WITH A TOTAL OF: 10,834 BBLS OF SLICKWATER, 112,000 LBS 20-40 SAND.
Tubing Size:2.375 in.Tubing Setting Depth:9359 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:7/28/2010Test Method:FLOWING
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 670
BTU_GAS 1170
CALC_BBLS_H2O 670
CALC_MCF_GAS 1033
CASING_PRESS 2600
MCF_GAS 1033
TUBING_PRESS 1400
Perforation Data:
Interval Top:9490 ft.# Of Holes:27
Interval Bottom:9651 ft.Hole Size:0.34 in.

Formation WMFK                     Formation Classification:  GW                     Status:  PR - 1/1/2019                  Interval Top: 7040 ft.    Interval Bottom: 8849 ft.

 Completed Information for Formation WILLIAMS FORK
1st Production Date:7/11/2010Choke Size:
Formation Name:WILLIAMS FORKCommingled:Yes
Production Method:
Open Hole Completion:
Formation Treatment
Treatment Date:6/30/2010
Treatment Summary:STAGES 3-11 TREATED WITH A TOTAL OF: 87,902 BBLS OF SLICKWATER, 925,800 LBS 20-40 SAND.
Tubing Size:2.375 in.Tubing Setting Depth:9359 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:7/28/2010Test Method:FLOWING
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 670
BTU_GAS 1170
CALC_BBLS_H2O 670
CALC_MCF_GAS 1033
CASING_PRESS 2600
MCF_GAS 1033
TUBING_PRESS 1400
Perforation Data:
Interval Top:7040 ft.# Of Holes:243
Interval Bottom:8849 ft.Hole Size:0.34 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
January 2025 - December 2025i
Total Oil Produced (Barrels)193
Total Gas Produced (MCF)31103
GOR161155
GOR DeterminationMCFE
Average BOE per Day15.224
Average MCFE per Day88.325

 Federal Financial Assurance  i Y

 Tribal Well  i No
