Wellbore #00 Wellbore Classification: GW Status: PR - 4/1/2012 Measured TD: 9555 ft. Vertical TD: 9487 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 4/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | 20082989 | Expiration Date: | 7/10/2009 | | Proposed Top PZ Location: | Sec: Twp: | Footage: 922 FNL 648 FWL | | Bottom Hole Location: | Sec:25 Twp: 5S 97W | Footage: 922 FNL 648 FWL | | Proposed Depth/Form: | 9663 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-17 , Unit Acreage: , Drill Unit: |
| | |
| Wellbore Completed | | Completion Date: | 12/19/2008 | | Spud Date: | 11/10/2008 | Spud Date Is: | ACTUAL | | Measured TD: | 9555 ft. | Measured PB depth: | 9534 ft. | | True Vertical TD: | 9487 ft. | True Vertical PB depth: | 9466 ft. | | Top PZ Location: | Sec:25 Twp: 5S 97W | Footage: 918 FNL 674 FWL | | Bottom Hole Location: | Sec:25 Twp: 5S 97W | Footage: 937 FNL 628 FWL | | Log Types: | CBL, RMTE, MUD | | Log Types: | CBL, RMTE, MUD | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 48 ft., Depth: 60 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: , Bottom: 60 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: 0 ft., Depth: 2770 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 1775, Top: , Bottom: 2770 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 9542 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 778, Top: 6100 ft., Bottom: 9542 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | MESAVERDE | 6396 ft. | | | | | CAMEO | 8991 ft. | | | | | ROLLINS | 9420 ft. | | | |
Formation WFCM Formation Classification: GW Status: PR - 4/1/2012 Interval Top: 7312 ft. Interval Bottom: 9394 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 7/7/2010 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Date: | 6/25/2010 | | Treatment Summary: | 3745 GALS OF 10% HCL ACID; 582610# 20/40 SAND; 17354 BBLS SLICKWATER (SUMMARY) |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 9300 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 10/20/2010 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1066 | | CASING_PRESS | 1312 | | MCF_GAS | 1086 | | TUBING_PRESS | 895 |
| | Perforation Data: | | Interval Top: | 7312 ft. | # Of Holes: | 76 | | Interval Bottom: | 9394 ft. | Hole Size: | 0.36 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 34 |
| Total Gas Produced (MCF) | 20018 |
| GOR | 588764 |
| GOR Determination | MCFE |
| Average BOE per Day | 9.547 |
| Average MCFE per Day | 55.395 |
| Federal Financial Assurance | i | |
|
|
