Wellbore #00 Wellbore Classification: GW Status: PR - 4/1/2012 Measured TD: 9645 ft. Vertical TD: 9491 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 4/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | 20082993 | Expiration Date: | 7/9/2009 | | Proposed Top PZ Location: | Sec: Twp: | Footage: 2365 FSL 594 FWL | | Bottom Hole Location: | Sec:25 Twp: 5S 97W | Footage: 2365 FSL 594 FWL | | Proposed Depth/Form: | 9745 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-17 , Unit Acreage: , Drill Unit: |
| | |
| Wellbore Completed | | Completion Date: | 10/13/2008 | | Spud Date: | 9/30/2008 | Spud Date Is: | ACTUAL | | Measured TD: | 9645 ft. | Measured PB depth: | 9573 ft. | | True Vertical TD: | 9491 ft. | True Vertical PB depth: | 9419 ft. | | Top PZ Location: | Sec:25 Twp: 5S 97W | Footage: 2360 FSL 620 FWL | | Bottom Hole Location: | Sec:25 Twp: 5S 97W | Footage: 2337 FSL 520 FWL | | Log Types: | CBL, RMTE, MUD | | Log Types: | CBL, HRI, SPECTRAL DENSITY, DUAL SPACED NEUTRON | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 60 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 60 ft., Determination Method: VISU | | Casing: | String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: 0 ft., Depth: 2860 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 1775, Top: 0 ft., Bottom: 2860 ft., Determination Method: VISU | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 9624 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 795, Top: 3400 ft., Bottom: 9624 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | MESAVERDE | 6423 ft. | | | | | CAMEO | 8999 ft. | | | | | ROLLINS | 9433 ft. | | | |
Formation WFCM Formation Classification: GW Status: PR - 4/1/2012 Interval Top: 7250 ft. Interval Bottom: 9403 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 8/6/2010 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Date: | 7/25/2010 | | Treatment Summary: | 10498 GALS 10% HCL ACID; 1613122# 20/40 SAND; 46990 BBLS SLICKWATER (SUMMARY) |
| | Tubing Size: | 2.38 in. | Tubing Setting Depth: | 9299 ft. | | Tubing Packer Depth: | 0 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 11/6/2010 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1057 | | CASING_PRESS | 1367 | | MCF_GAS | 1257 | | TUBING_PRESS | 1096 |
| | Perforation Data: | | Interval Top: | 7250 ft. | # Of Holes: | 235 | | Interval Bottom: | 9403 ft. | Hole Size: | 0.36 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 36 |
| Total Gas Produced (MCF) | 22130 |
| GOR | 614722 |
| GOR Determination | MCFE |
| Average BOE per Day | 10.559 |
| Average MCFE per Day | 61.232 |
| Federal Financial Assurance | i | |
|
|
