Wellbore #00 Wellbore Classification: GW Status: PR - 5/1/2012 Measured TD: 10170 ft. Vertical TD: 9586 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 5/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 3/10/2011 | | Proposed Top PZ Location: | Sec:31 Twp: 5S 96W | Footage: 1520 FSL 720 FEL | | Bottom Hole Location: | Sec:31 Twp: 5S 96W | Footage: 1520 FSL 720 FEL | | Proposed Depth/Form: | 9602 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-18 , Unit Acreage: 320, Drill Unit: S/2 | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: , Depth: 90 ft., Weight: 55 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 90 ft. | | Casing: | String Type: SURF, Hole Size: 16 in., Size: 9.625 in., Top: , Depth: 2000 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 1000, Top: 0 ft., Bottom: 2000 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 9602 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1200, Top: 6500 ft., Bottom: 9602 ft. | | Casing: | String Type: 3RD, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 9602 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 600, Top: 200 ft., Bottom: 9602 ft. |
| | |
| Wellbore Completed | | Completion Date: | 6/21/2010 | | Spud Date: | 6/10/2010 | Spud Date Is: | ACTUAL | | Measured TD: | 10170 ft. | Measured PB depth: | 10108 ft. | | True Vertical TD: | 9586 ft. | True Vertical PB depth: | 9524 ft. | | Top PZ Location: | Sec:31 Twp: 5S 96W | Footage: 2438 FNL 1050 FWL | | Bottom Hole Location: | Sec:31 Twp: 5S 96W | Footage: 2398 FNL 982 FWL | | Log Types: | RST PACKAGE, MUD LOG | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: 0 ft., Depth: 102 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 350, Top: 0 ft., Bottom: 123 ft., Determination Method: CALC | | Casing: | String Type: SURF, Hole Size: 16 in., Size: 9.625 in., Top: 0 ft., Depth: 2520 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 1244, Top: 0 ft., Bottom: 2520 ft., Determination Method: CALC | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 10152 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 687, Top: 3676 ft., Bottom: 10152 ft., Determination Method: | | Formation | Interval Top | Log Bottom | Cored | DSTs | | OHIO CREEK | 6871 ft. | | | | | WILLIAMS FORK | 7104 ft. | | | | | CAMEO | 9737 ft. | | | | | ROLLINS | 10012 ft. | | | |
Formation WMFK Formation Classification: GW Status: PR - 5/1/2012 Interval Top: 7940 ft. Interval Bottom: 9688 ft.| Completed Information for Formation WILLIAMS FORK | | 1st Production Date: | 7/27/2010 | Choke Size: | | | Formation Name: | WILLIAMS FORK | Commingled: | | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Date: | 7/15/2010 | | Treatment Summary: | WELL FRAC'D IN 7 STAGES USING 41,987 BBLS SLICK WATER AND 848,861 LBS OF 30/50 WHITE SAND. |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 9425 ft. | | Tubing Packer Depth: | 0 ft. | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 7/27/2010 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1100 | | BTU_GAS | 1054 | | CALC_BBLS_H2O | 1100 | | CALC_MCF_GAS | 1300 | | CASING_PRESS | 1460 | | MCF_GAS | 1300 | | TUBING_PRESS | 980 |
| | Perforation Data: | | Interval Top: | 7940 ft. | # Of Holes: | 178 | | Interval Bottom: | 9688 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 40 |
| Total Gas Produced (MCF) | 20195 |
| GOR | 504875 |
| GOR Determination | MCFE |
| Average BOE per Day | 8.850 |
| Average MCFE per Day | 51.331 |
| Federal Financial Assurance | i | |
|
|
