COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-15095		Well Classification: LO Status: AL - 6/2/2011
Well Name/No:DWU #CP02D-33 E34 49
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:ENCANA OIL & GAS (USA) INC - 100185
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:COC-65556
Facility Status:ALStatus Date6/2/2011
FacilityID:293669LocationID:335928
County:GARFIELD #045Location:SWNW 34 4S96W 6
Field:WILDCAT - #99999Elevation:8325 ft.
Basin:PICEANCE BASIN
Planned Location:2118FNL  1008 FWLLat/Long: 39.660253 / -108.160550Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification:              Status: AL - 6/2/2011             Measured TD:

 Wellbore Data for Original WellboreWellbore Classification:         AL - 6/2/2011
Wellbore PermitDIRECTIONAL
Permit #:20075195 Expiration Date:11/25/2008
Proposed Top PZ Location:Sec: Twp: Footage: 990 FNL  1650 FEL
Bottom Hole Location:Sec:33 Twp: 4S 96W Footage: 990 FNL  1650 FEL
Proposed Depth/Form:13025 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEDERALSurface Owner:FEE
Unit:DOUBLE WILLOW U Unit Number:COC-67498X
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: CONDUCTOR, Hole Size: 20 in., Size: 16 in., Top: , Depth: 80 ft., Weight: , Citings Type: PLANNED
Cement:Sacks: , Top: 0 ft., Bottom: 80 ft.
Casing:String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: , Depth: 2000 ft., Weight: 36 , Citings Type: PLANNED
Cement:Sacks: 926, Top: 0 ft., Bottom: 2000 ft.
Casing:String Type: 1ST, Hole Size: 8.75 in., Size: 7 in., Top: , Depth: 8102 ft., Weight: 23 , Citings Type: PLANNED
Cement:Sacks: 465, Top: 1900 ft., Bottom: 8102 ft.
Casing:String Type: 2ND, Hole Size: 6.125 in., Size: 4.5 in., Top: , Depth: 13025 ft., Weight: 13.5 , Citings Type: PLANNED
Cement:Sacks: 1214, Top: 7802 ft., Bottom: 13025 ft.
Wellbore Completed
Completion Date:N/A
Measured TD:Measured PB depth:
True Vertical TD:True Vertical PB depth:
  No formation data to display.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)0
GOR
GOR Determination
Average BOE per Day0.000
Average MCFE per Day0.000

 Federal Financial Assurance  i

 Tribal Well  i No
