Wellbore #00 Wellbore Classification: GW Status: PR - 5/1/2012 Measured TD: 10220 ft. Vertical TD: 10085 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 5/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | | Expiration Date: | 8/3/2012 | | Proposed Top PZ Location: | Sec:15 Twp: 6S 96W | Footage: 625 FSL 1160 FWL | | Bottom Hole Location: | Sec:15 Twp: 6S 96W | Footage: 625 FSL 1160 FWL | | Proposed Depth/Form: | 10374 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-13 , Unit Acreage: , Drill Unit: NWSW | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: , Depth: 90 ft., Weight: 55 , Citings Type: PLANNED | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 90 ft. | | Casing: | String Type: SURF, Hole Size: 16 in., Size: 9.625 in., Top: , Depth: 2500 ft., Weight: 36 , Citings Type: PLANNED | | Cement: | Sacks: 1000, Top: 0 ft., Bottom: 2500 ft. | | Casing: | String Type: 1ST, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 10174 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 1200, Top: 6500 ft., Bottom: 10174 ft. | | Casing: | String Type: 3RD, Hole Size: 8.75 in., Size: 4.5 in., Top: , Depth: 10374 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: 600, Top: , Bottom: 10374 ft. |
| | |
| Wellbore Completed | | Completion Date: | 2/23/2011 | | Spud Date: | 2/11/2011 | Spud Date Is: | ACTUAL | | Measured TD: | 10220 ft. | Measured PB depth: | 10140 ft. | | True Vertical TD: | 10085 ft. | True Vertical PB depth: | 10005 ft. | | Top PZ Location: | Sec:15 Twp: 6S 96W | Footage: 625 FSL 1160 FWL | | Bottom Hole Location: | Sec:15 Twp: 6S 96W | Footage: 625 FSL 1160 FWL | | Log Types: | RST, CBL, Caliper (2), Density, Induction, Triple Combo Quicklook (2) | | Casing: | String Type: CONDUCTOR, Hole Size: 30 in., Size: 20 in., Top: 0 ft., Depth: 100 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 276, Top: 0 ft., Bottom: 100 ft., Determination Method: CALC | | Casing: | String Type: SURF, Hole Size: 16 in., Size: 9.625 in., Top: 100 ft., Depth: 2811 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 1322, Top: 0 ft., Bottom: 2811 ft., Determination Method: CALC | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 2811 ft., Depth: 10187 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 657, Top: 4436 ft., Bottom: 10187 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WILLIAMS FORK | 7207 ft. | 9762 ft. | | | | CAMEO | 9762 ft. | 10040 ft. | | | | ROLLINS | 10040 ft. | 10187 ft. | | |
Formation WFCM Formation Classification: GW Status: PR - 5/1/2012 Interval Top: 7707 ft. Interval Bottom: 9755 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 4/12/2011 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Date: | 3/30/2011 | | Treatment Summary: | 20/40 whitesand- 329,281 lbs 30/50 whitesand- 138,394 lbs Fluid- 50,358 barrels Acid- 2,500 gals |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 9352 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 4/13/2011 | Test Method: | Flowing | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 1012 | | BTU_GAS | 1060 | | CALC_BBLS_H2O | 1012 | | CALC_MCF_GAS | 1900 | | CASING_PRESS | 2034 | | MCF_GAS | 1900 | | TUBING_PRESS | 967 |
| | Perforation Data: | | Interval Top: | 7707 ft. | # Of Holes: | 168 | | Interval Bottom: | 9755 ft. | Hole Size: | 0.4 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 62 |
| Total Gas Produced (MCF) | 28040 |
| GOR | 452258 |
| GOR Determination | MCFE |
| Average BOE per Day | 13.412 |
| Average MCFE per Day | 77.812 |
| Federal Financial Assurance | i | |
|
|
