Wellbore #00 Wellbore Classification: GW Status: PR - 8/1/2023 Measured TD: 8852 ft. Vertical TD: 8852 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 8/1/2023 | | Wellbore Permit | DIRECTIONAL | | Permit #: | 20074162 | Expiration Date: | 10/3/2008 | | Proposed Top PZ Location: | Sec: Twp: | Footage: 736 FSL 443 FEL | | Bottom Hole Location: | Sec:14 Twp: 6S 96W | Footage: 736 FSL 443 FEL | | Proposed Depth/Form: | 8856 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-12 , Unit Acreage: , Drill Unit: S/2 | | Casing: | String Type: CONDUCTOR, Hole Size: 22 in., Size: 18 in., Top: , Depth: 60 ft., Weight: , Citings Type: PLANNED | | Cement: | Sacks: , Top: 0 ft., Bottom: 60 ft. | | Casing: | String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: , Depth: 1122 ft., Weight: 32.3 , Citings Type: PLANNED | | Cement: | Sacks: , Top: 0 ft., Bottom: 1119 ft. | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: , Depth: 8856 ft., Weight: 11.6 , Citings Type: PLANNED | | Cement: | Sacks: , Top: 200 ft., Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 9/3/2008 | | Spud Date: | 5/27/2008 | Spud Date Is: | Actual | | Measured TD: | 8852 ft. | Measured PB depth: | 8850 ft. | | True Vertical TD: | 8852 ft. | True Vertical PB depth: | 8850 ft. | | Top PZ Location: | Sec:14 Twp: 6S 96W | Footage: 734 FSL 441 FEL | | Bottom Hole Location: | Sec:14 Twp: 6S 96W | Footage: 732 FSL 455 FEL | | Log Types: | CBL, MUD, RMTE | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 60 ft., Weight: 48 , Citings Type: ACTUAL | | Cement: | Sacks: 100, Top: 0 ft., Bottom: 60 ft., Determination Method: | | Casing: | String Type: SURF, Hole Size: 14.75 in., Size: 9.625 in., Top: 0 ft., Depth: 2521 ft., Weight: 32.3 , Citings Type: ACTUAL | | Cement: | Sacks: 530, Top: 0 ft., Bottom: 2521 ft., Determination Method: | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 8837 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 931, Top: 7235 ft., Bottom: 8837 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | MESAVERDE | 5522 ft. | | N | N | | CAMEO | 8252 ft. | | N | N | | ROLLINS | 8733 ft. | | N | N |
Formation WFCM Formation Classification: GW Status: PR - 8/1/2023 Interval Top: 6854 ft. Interval Bottom: 8705 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 6/2/2009 | Choke Size: | | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | |
| | Formation Treatment | | Treatment Date: | 6/2/2009 | | Treatment Summary: | 62050 GAL 10% HCL ACID, 901509# 100 MESH AND 30/550 SAND, 29666 BBLS SLICKWATER |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8504 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 6/2/2009 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 0 | | BBLS_OIL | 0 | | BTU_GAS | 989 | | CALC_GOR | 0 | | CASING_PRESS | 1750 | | GRAVITY_OIL | 52 | | MCF_GAS | 1900 | | TUBING_PRESS | 1700 |
| | Perforation Data: | | Interval Top: | 6854 ft. | # Of Holes: | 142 | | Interval Bottom: | 8705 ft. | Hole Size: | 0.36 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 33 |
| Total Gas Produced (MCF) | 23500 |
| GOR | 712121 |
| GOR Determination | MCFE |
| Average BOE per Day | 11.195 |
| Average MCFE per Day | 64.920 |
| Federal Financial Assurance | i | |
|
|
