Wellbore #00 Wellbore Classification: GW Status: PR - 5/7/2007 Measured TD: 8570 ft. Vertical TD: 8373 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW PR - 5/7/2007 | | Wellbore Permit | DIRECTIONAL | | Permit #: | 20072512 | Expiration Date: | 6/13/2008 | | Proposed Top PZ Location: | Sec: Twp: | Footage: 139 FNL 692 FEL | | Bottom Hole Location: | Sec:1 Twp: 7S 95W | Footage: 139 FNL 692 FEL | | Proposed Depth/Form: | 8694 ft. | | Surface Mineral Owner Same: | No | | Mineral Owner: | FEE | Surface Owner: | FEE | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: , Unit Acreage: , Drill Unit: |
| | |
| Wellbore Completed | | Completion Date: | 3/21/2008 | | Spud Date: | 3/9/2008 | Spud Date Is: | ACTUAL | | Measured TD: | 8570 ft. | Measured PB depth: | 8520 ft. | | True Vertical TD: | 8373 ft. | True Vertical PB depth: | 8323 ft. | | Top PZ Location: | Sec:1 Twp: 7S 95W | Footage: 107 FNL 704 FEL | | Bottom Hole Location: | Sec:1 Twp: 7S 95W | Footage: 107 FNL 704 FEL | | Log Types: | CBL; RMTE; MUD | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 45 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 25, Top: 0 ft., Bottom: 45 ft., Determination Method: | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 2867 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 628, Top: 0 ft., Bottom: 2867 ft., Determination Method: | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 8551 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 993, Top: 3510 ft., Bottom: 8551 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 2542 ft. | | N | N | | MESAVERDE | 5023 ft. | | N | N | | CAMEO | 7573 ft. | | N | N | | ROLLINS | 8518 ft. | | N | N |
Formation WFCM Formation Classification: GW Status: PR - 6/29/2008 Interval Top: 6437 ft. Interval Bottom: 8433 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 5/11/2008 | Choke Size: | 0.172 in. | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 4/29/2008 | | Treatment Summary: | 3508 GALS 7.5% HCL; 751,947# 20/40 SAND; 26,524 BBLS SLICKWATER |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 7830 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 6/29/2008 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BTU_GAS | 1035 | | CASING_PRESS | 2074 | | MCF_GAS | 1323 | | TUBING_PRESS | 1924 |
| | Perforation Data: | | Interval Top: | 6437 ft. | # Of Holes: | 134 | | Interval Bottom: | 8433 ft. | Hole Size: | 0.35 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 26 |
| Total Gas Produced (MCF) | 21379 |
| GOR | 822269 |
| GOR Determination | MCFE |
| Average BOE per Day | 10.175 |
| Average MCFE per Day | 59.018 |
| Federal Financial Assurance | i | |
|
|
