Facility Detail

COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-12992		Well Classification: GW Status: PR - 9/1/2007
Well Name/No:LAST DANCE #34-15 (P34NE)
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date9/1/2007
FacilityID:287372LocationID:334620
County:GARFIELD #045Location:SESE 34 6S92W 6
Field:MAMM CREEK - #52500Elevation:5967 ft.
Basin:PICEANCE BASIN
Planned Location:623FSL  1128 FELLat/Long: 39.478140 / -107.647180Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.478142 / -107.647172Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 9/1/2007             Measured TD: 6672 ft.    Vertical TD: 6554 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 9/1/2007
Wellbore PermitDIRECTIONAL
Permit #:20064408 Expiration Date:10/12/2007
Proposed Top PZ Location:Sec: Twp: Footage: 1060 FSL  1980 FEL
Bottom Hole Location:Sec:34 Twp: 6S 92 Footage: 1060 FSL  1980 FEL
Proposed Depth/Form:6672 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: 191-8 , Unit Acreage: 80, Drill Unit: S2SE
Wellbore Completed
Completion Date:6/21/2007
Spud Date:6/9/2007Spud Date Is:ACTUAL
Measured TD:6672 ft.Measured PB depth:
True Vertical TD:6554 ft.True Vertical PB depth:
Top PZ Location:Sec:34 Twp: 6S 92WFootage: 1045 FSL  1987 FEL
Bottom Hole Location:Sec:34 Twp: 6S 92WFootage: 1045 FSL  1987 FEL
Log Types:CBL, PEX
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 40 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: 0 ft., Bottom: 40 ft., Determination Method:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 1108 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 560, Top: 0 ft., Bottom: 1108 ft., Determination Method: CBL
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 6665 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 650, Top: 3275 ft., Bottom: 6672 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WASATCH0 ft.3445 ft.NN
WILLIAMS FORK3446 ft.6575 ft.NN
ROLLINS6576 ft.6672 ft.NN

Formation WMFK                     Formation Classification:  GW                     Status:  PR - 9/1/2007                  Interval Top: 4512 ft.    Interval Bottom: 6413 ft.

 Completed Information for Formation WILLIAMS FORK
1st Production Date:8/25/2007Choke Size:0.250 in.
Formation Name:WILLIAMS FORKCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:8/12/2007
Treatment Summary:STAGES 1-05 TREATED WITH A TOTAL OF 32,514 BBLS OF SLICKWATER,775,974 LBS 20-40 WHITE SAND, AND 11,800 LBS NON API SAND.
Tubing Size:2.375 in.Tubing Setting Depth:4517 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:9/1/2007Test Method:FLOWING
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 380
BBLS_OIL 2
BTU_GAS 1170
CALC_BBLS_H2O 380
CALC_BBLS_OIL 2
CALC_GOR 546000
CALC_MCF_GAS 1092
CASING_PRESS 2050
GRAVITY_OIL 52
MCF_GAS 1092
TUBING_PRESS 1600
Perforation Data:
Interval Top:4512 ft.# Of Holes:140
Interval Bottom:6413 ft.Hole Size:0.34 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)109
Total Gas Produced (MCF)24976
GOR229137
GOR DeterminationMCFE
Average BOE per Day12.099
Average MCFE per Day70.176

 Federal Financial Assurance  i

 Tribal Well  i No
