 Surface Location
 API# 05-045-11658		Well Classification: GW Status: PR - 11/9/2006
Well Name/No:N.PARACHUTE #EF 15D G29 595
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date11/9/2006
FacilityID:282111LocationID:335573
County:GARFIELD #045Location:SWNE 29 5S95W 6
Field:GRAND VALLEY - #31290Elevation:6102 ft.
Basin:PICEANCE BASIN
Planned Location:2273FNL  1553 FELLat/Long: 39.585761 / -108.074137Lat/Long Source: Field Measured
As Drilled Location:Footages Not AvailableLat/Long: 39.585837 / -108.074170Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 11/9/2006             Measured TD: 10040 ft.    Vertical TD: 9432 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 11/9/2006
Wellbore PermitDIRECTIONAL
Permit #:20065900 Expiration Date:11/28/2007
Proposed Top PZ Location:Sec: Twp: Footage: 330 FSL  1650 FEL
Bottom Hole Location:Sec:29 Twp: 5S 95W Footage: 330 FSL  1650 FEL
Proposed Depth/Form:11144 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: 510-13 , Unit Acreage: , Drill Unit:
Wellbore Completed
Completion Date:3/25/2007
Spud Date:3/12/2007Spud Date Is:ACTUAL
Measured TD:10040 ft.Measured PB depth:10006 ft.
True Vertical TD:9432 ft.True Vertical PB depth:
Top PZ Location:Sec:29 Twp: 5S 95WFootage: 459 FSL  1593 FEL
Bottom Hole Location:Sec:29 Twp: 5S 95WFootage: 459 FSL  1593 FEL
Log Types:CBL, MUD
Casing:String Type: CONDUCTOR, Hole Size: 24 in., Size: 16 in., Top: 0 ft., Depth: 120 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: , Top: 0 ft., Bottom: 120 ft., Determination Method: CALC
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 9.625 in., Top: 0 ft., Depth: 2494 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 910, Top: 0 ft., Bottom: 2505 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 8.875 in., Size: 4.5 in., Top: 0 ft., Depth: 10029 ft., Weight: , Citings Type: ACTUAL
Cement:Sacks: 1455, Top: 2300 ft., Bottom: 10040 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WILLIAMS FORK6318 ft.9924 ft.NN
ROLLINS9924 ft.10040 ft.NN

Formation WMFK                     Formation Classification:  GW                     Status:  PR - 2/5/2008                  Interval Top: 8253 ft.    Interval Bottom: 9823 ft.

 Completed Information for Formation WILLIAMS FORK
1st Production Date:9/1/2007Choke Size:0.375 in.
Formation Name:WILLIAMS FORKCommingled:No
Production Method:
Open Hole Completion:No
Formation Treatment
Treatment Date:8/4/2007
Treatment Summary:STAGES 01-05 TREATED W/TOTAL 11,979 BBL SLICKWATER, 52,081 LBS 20-40 SAND, 158,486 LBS 30-50 SAND AND 36 BBL 15% HCL.
Tubing Size:2.375 in.Tubing Setting Depth:8202 ft.
Tubing Packer Depth:8198 ft.Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:2/5/2008Test Method:FLOWING
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BTU_GAS 1170
MCF_GAS 222
Perforation Data:
Interval Top:8253 ft.# Of Holes:150
Interval Bottom:9823 ft.Hole Size:0.43 in.
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
September 2024 - August 2025i
Total Oil Produced (Barrels)80
Total Gas Produced (MCF)14231
GOR177887
GOR DeterminationMCFE
Average BOE per Day6.943
Average MCFE per Day40.282

 Federal Financial Assurance  i

 Tribal Well  i No
