Wellbore #00 Wellbore Classification: GW Status: AB - 8/17/1960 Measured TD: 4053 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: GW AB - 8/17/1960 | | Wellbore Permit | DIRECTIONAL | | Permit #: | 20050914 | Expiration Date: | 4/14/2006 | | Proposed Top PZ Location: | Sec: Twp: | Footage: 1747 FNL 235 FWL | | Bottom Hole Location: | Sec: Twp: | Footage: 1747 FNL 235 FWL | | Proposed Depth/Form: | 9004 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEDERAL | Surface Owner: | FEDERAL | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 139-40 , Unit Acreage: 320, Drill Unit: N2 |
| | |
| Wellbore Completed | | Completion Date: | 10/11/2005 | | Spud Date: | 9/29/2005 | Spud Date Is: | ACTUAL | | Measured TD: | 4053 ft. | Measured PB depth: | 3790 ft. | | True Vertical TD: | | True Vertical PB depth: | | | Bottom Hole Location: | Sec: Twp: | Footage: 1747 FNL 235 FWL | | Log Types: | CBL; RESERVOIR MONITOR TOOL ELITE | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 45 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 25, Top: 0 ft., Bottom: 45 ft., Determination Method: CALC | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1135 ft., Weight: 32.3 , Citings Type: ACTUAL | | Cement: | Sacks: 350, Top: 0 ft., Bottom: 1135 ft., Determination Method: CALC | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: , Weight: , Citings Type: ACTUAL | | Cement: | Sacks: , Top: , Bottom: , Determination Method: | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 2923 ft. | | N | N | | No formation data to display. |
Sidetrack #01 Wellbore Classification: GW Status: PR - 11/1/2008 Measured TD: 9033 ft. Vertical TD: 8959 ft.| Wellbore Data for Sidetrack #01 | Wellbore Classification: GW PR - 11/1/2008 | | Wellbore Permit | | | Permit #: | 20063298 | Expiration Date: | 7/17/2007 | | Proposed Top PZ Location: | Sec: Twp: | Footage: 1770 FNL 263 FWL | | Bottom Hole Location: | Sec:16 Twp: 6S 94W | Footage: 1777 FNL 273 FWL | | Proposed Depth/Form: | 9033 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEDERAL | Surface Owner: | FEDERAL | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 510-9 , Unit Acreage: , Drill Unit: |
| | |
| Wellbore Completed | | Completion Date: | 10/28/2005 | | Spud Date: | 9/29/2005 | Spud Date Is: | ACTUAL | | Measured TD: | 9033 ft. | Measured PB depth: | 8885 ft. | | True Vertical TD: | 8959 ft. | True Vertical PB depth: | | | Top PZ Location: | Sec:18 Twp: 6S 94W | Footage: 1770 FNL 263 FWL | | Bottom Hole Location: | Sec:18 Twp: 6S 94W | Footage: 1770 FNL 263 FWL | | Log Types: | CBL: RESERVOIR MONITOR TOOL ELITE | | Casing: | String Type: CONDUCTOR, Hole Size: 24 in., Size: 18 in., Top: 0 ft., Depth: 45 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 25, Top: 0 ft., Bottom: 45 ft., Determination Method: CALC | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1135 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 350, Top: 0 ft., Bottom: 1135 ft., Determination Method: CALC | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 9013 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 1020, Top: 4050 ft., Bottom: 9013 ft., Determination Method: CBL | | Casing: | String Type: S.C. 1.1, Hole Size: , Size: , Top: , Depth: 4492 ft., Weight: , Citings Type: ACTUAL | | Cement: | Sacks: 250, Top: 3379 ft., Bottom: 4492 ft., Determination Method: CALC | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 2923 ft. | | N | N | | MESAVERDE | 5391 ft. | | N | N | | CAMEO | 7975 ft. | | N | N | | ROLLINS | 8843 ft. | | N | N |
Formation WFCM Formation Classification: GW Status: PR - 11/1/2008 Interval Top: 6760 ft. Interval Bottom: 8801 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | 1/10/2006 | Choke Size: | 0.313 in. | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 1/8/2006 | | Treatment Summary: | 3276 GALS 10% ACETIC ACID, 1009 GALS 7 1/2% HCL; 632,300# 20/40 SAND; 15,148 BBLS SLICKWATER. [PERF HOLES SIZE 34/100 & 42/100] |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 8586 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 3/1/2006 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | DRY | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| BBLS_H2O | 0 | | BBLS_OIL | 0 | | CASING_PRESS | 1513 | | MCF_GAS | 1239 | | TUBING_PRESS | 1306 |
| | Perforation Data: | | Interval Top: | 6760 ft. | # Of Holes: | 121 | | Interval Bottom: | 8801 ft. | Hole Size: | 0.34 in. |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 47 |
| Total Gas Produced (MCF) | 10727 |
| GOR | 228234 |
| GOR Determination | MCFE |
| Average BOE per Day | 5.190 |
| Average MCFE per Day | 30.136 |
| Federal Financial Assurance | i | Y |
|
|
