Wellbore #00 Wellbore Classification: OW Status: PR - 5/1/2012 Measured TD: 7158 ft.| Wellbore Data for Original Wellbore | Wellbore Classification: OW PR - 5/1/2012 | | Wellbore Permit | DIRECTIONAL | | Permit #: | 20031504 | Expiration Date: | 9/4/2004 | | Proposed Top PZ Location: | Sec: Twp: | Footage: 862 FNL 1547 FEL | | Bottom Hole Location: | Sec: Twp: | Footage: 862 FNL 1547 FEL | | Proposed Depth/Form: | 7150 ft. | | Surface Mineral Owner Same: | Yes | | Mineral Owner: | FEDERAL | Surface Owner: | FEDERAL | | Unit: | | Unit Number: | | | Formation And Spacing: | Code: WMFK , Formation: WILLIAMS FORK , Order: 139-40 , Unit Acreage: 160, Drill Unit: NE/4 | | Casing: | String Type: CONDUCTOR, Hole Size: , Size: 16 in., Top: , Depth: 45 ft., Weight: , Citings Type: PLANNED | | Cement: | Sacks: , Top: , Bottom: |
| | |
| Wellbore Completed | | Completion Date: | 12/31/2003 | | Spud Date: | 11/1/2003 | Spud Date Is: | ACTUAL | | Measured TD: | 7158 ft. | Measured PB depth: | 7104 ft. | | True Vertical TD: | | True Vertical PB depth: | | | Top PZ Location: | Sec: Twp: | Footage: 862 FNL 1547 FEL | | Bottom Hole Location: | Sec: Twp: | Footage: 862 FNL 1547 FEL | | Log Types: | DUAL IND.,SPECTRAL DEN. DUAL SPACED NEU.,CBL | | Casing: | String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: 0 ft., Depth: 1898 ft., Weight: 32.3 , Citings Type: ACTUAL | | Cement: | Sacks: 705, Top: , Bottom: 1898 ft., Determination Method: | | Casing: | String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7143 ft., Weight: 11.6 , Citings Type: ACTUAL | | Cement: | Sacks: 921, Top: 4200 ft., Bottom: 7142 ft., Determination Method: CBL | | Formation | Interval Top | Log Bottom | Cored | DSTs | | WASATCH G | 1640 ft. | | N | N | | FORT UNION | 2028 ft. | | N | N | | MESAVERDE | 3718 ft. | | N | N | | CAMEO | 6361 ft. | | N | N | | ROLLINS | 7073 ft. | | N | N |
Formation WFCM Formation Classification: OW Status: PR - 5/1/2012 Interval Top: 5112 ft. Interval Bottom: 7013 ft.| Completed Information for Formation WILLIAMS FORK - CAMEO | | 1st Production Date: | N/A | Choke Size: | 0.219 in. | | Formation Name: | WILLIAMS FORK - CAMEO | Commingled: | No | | Production Method: | FLOWING | | Open Hole Completion: | No |
| | Formation Treatment | | Treatment Date: | 12/31/2003 | | Treatment Summary: | |
| | Tubing Size: | 2.375 in. | Tubing Setting Depth: | 6605 ft. | | Tubing Packer Depth: | | Tubing Multiple Packer: | | | Open Hole Top: | | Open Hole Bottom: | | | Initial Test Data: | | Test Date: | 11/8/2004 | Test Method: | FLOWING | | Hours Tested: | 24 | Gas Type: | | | Gas Disposal: | SOLD | |
| Test Type | Measure |
|---|
| CALC_MCF_GAS | 1215 | | CASING_PRESS | 1363 | | MCF_GAS | 1215 | | TUBING_PRESS | 1234 |
| | Perforation Data: | | Interval Top: | 5112 ft. | # Of Holes: | 69 | | Interval Bottom: | 7013 ft. | Hole Size: | |
|
|
|
|
|
|
|
| Reported Plugged | N | |
| Out Of Service Repurposed | N | |
| Out Of Service | N | |
| Inactive Exception | N | |
| Noticed Inactive | N | |
| Defined Inactive | N | |
| Low Producing | N | |
| Total Oil Produced (Barrels) | 13 |
| Total Gas Produced (MCF) | 11024 |
| GOR | 848000 |
| GOR Determination | MCFE |
| Average BOE per Day | 5.248 |
| Average MCFE per Day | 30.423 |
| Federal Financial Assurance | i | Y |
|
|
