 Surface Location
 API# 05-045-09331		Well Classification: GW Status: PR - 9/6/2007
Well Name/No:BENZEL #36-8C5 (H36X
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date9/6/2007
FacilityID:269190LocationID:335003
County:GARFIELD #045Location:SENE 36 6S93W 6
Field:MAMM CREEK - #52500Elevation:5937 ft.
Basin:PICEANCE BASIN
Planned Location:2416FNL  599 FELLat/Long: 39.483811 / -107.716734Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 39.483900 / -107.716720Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 9/6/2007             Measured TD: 7609 ft.    Vertical TD: 7587 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 9/6/2007
Wellbore PermitDIRECTIONAL
Permit #:20031459 Expiration Date:8/24/2004
Proposed Top PZ Location:Sec: Twp: Footage: 2312 FNL  990 FEL
Bottom Hole Location:Sec:36 Twp: Footage: 2310 FNL  990 FEL
Proposed Depth/Form:8200 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEESurface Owner:FEE
Unit:GRASS MESA UNIT Unit Number:COC 56608X
Formation And Spacing:Code: RLNS , Formation: ROLLINS , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: , Unit Acreage: , Drill Unit:
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: , Depth: 820 ft., Weight: 24 , Citings Type: PLANNED
Cement:Sacks: 564, Top: 0 ft., Bottom: 820 ft.
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: , Depth: 8200 ft., Weight: 11.6 , Citings Type: PLANNED
Cement:Sacks: 1313, Top: 1500 ft., Bottom: 8200 ft.
Wellbore Completed
Completion Date:2/13/2004
Spud Date:9/25/2003Spud Date Is:ACTUAL
Measured TD:7609 ft.Measured PB depth:7550 ft.
True Vertical TD:7587 ft.True Vertical PB depth:0 ft.
Top PZ Location:Sec: Twp: Footage: 2312 FNL  990 FEL
Bottom Hole Location:Sec:36 Twp: Footage: 2310 FNL  990 FEL
Log Types:PEX-AIT (HIGH RES), PEX/AIT/GR, UIT/GR/CCL, CHDT/GR
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 920 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 475, Top: 0 ft., Bottom: 925 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 5.5 in., Top: 0 ft., Depth: 7599 ft., Weight: 17 , Citings Type: ACTUAL
Cement:Sacks: 1055, Top: 2600 ft., Bottom: 7609 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WASATCH0 ft.4173 ft.NN
WILLIAMS FORK1074 ft.7357 ft.NN
ROLLINS7358 ft.7609 ft.NN

Formation RLNS                     Formation Classification:  GW                     Status:  PR - 9/6/2007                  Interval Top: 7403 ft.    Interval Bottom: 7411 ft.

 Completed Information for Formation ROLLINS
1st Production Date:N/AChoke Size:0.375 in.
Formation Name:ROLLINSCommingled:No
Production Method:FLOWING
Open Hole Completion:No
Formation Treatment
Treatment Date:2/13/2004
Treatment Summary:STAGE 1: ACID BLLOUT, 7403-7411, 16-0.360" SHOTS, 2027 BBLS SLICKWATER, 67500# 20/40 SAND.
Tubing Size:2.375 in.Tubing Setting Depth:6700 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:1/29/2004Test Method:FLOWING
Hours Tested:24Gas Type:
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 31
BBLS_OIL 1
BTU_GAS 1170
CALC_BBLS_H2O 31
CALC_BBLS_OIL 1
CALC_GOR 129
CALC_MCF_GAS 129
CASING_PRESS 950
MCF_GAS 129
Perforation Data:
Interval Top:7403 ft.# Of Holes:16
Interval Bottom:7411 ft.Hole Size:

Formation WMFK                     Formation Classification:  GW                     Status:  PR - 9/6/2007                  Interval Top: 5318 ft.    Interval Bottom: 7032 ft.

 Completed Information for Formation WILLIAMS FORK
1st Production Date:N/AChoke Size:0.375 in.
Formation Name:WILLIAMS FORKCommingled:No
Production Method:FLOWING
Open Hole Completion:No
Formation Treatment
Treatment Date:2/13/2004
Treatment Summary:STAGE 2: ACID BLLOUT, 6902-7032, 16-0.360" SHOTS, 3893 BBLS OF SLICKWATER, 168000# 20/40 SAND, STAGE 3: ACID BALLOUT 6707-6868, 16-0.360" SHOTS, 3401 BBLS OF SLICKWATER, 99500# 20/40 SAND, STAGE 4: ACID BALLOUT, 6518-6629, 16-0.360" SHOTS - CONT'D
Tubing Size:2.375 in.Tubing Setting Depth:6700 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:1/29/2004Test Method:FLOWING
Hours Tested:24Gas Type:
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 281
BBLS_OIL 7
BTU_GAS 1170
CALC_BBLS_H2O 281
CALC_BBLS_OIL 7
CALC_GOR 166
CALC_MCF_GAS 1161
CASING_PRESS 950
MCF_GAS 1161
Perforation Data:
Interval Top:5318 ft.# Of Holes:104
Interval Bottom:7032 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)14
Total Gas Produced (MCF)14642
GOR1045857
GOR DeterminationMCFE
Average BOE per Day6.953
Average MCFE per Day40.338

 Federal Financial Assurance  i Y

 Tribal Well  i No
