COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-09101		Well Classification: GW Status: PR - 11/16/2003
Well Name/No:SHAEFFER #12-9C (P12W)
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date11/16/2003
FacilityID:265951LocationID:334823
County:GARFIELD #045Location:SESE 12 7S93W 6
Field:MAMM CREEK - #52500Elevation:6241 ft.
Basin:PICEANCE BASIN
Planned Location:787FSL  820 FELLat/Long: 39.455381 / -107.717364Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 39.455680 / -107.717070Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 11/16/2003             Measured TD: 7729 ft.    Vertical TD: 7588 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 11/16/2003
Wellbore PermitDIRECTIONAL
Permit #:20030115 Expiration Date:1/28/2004
Proposed Top PZ Location:Sec:12 Twp: Footage: 1310 FSL  1298 FEL
Bottom Hole Location:Sec:12 Twp: Footage: 1330 FSL  1310 FEL
Proposed Depth/Form:7900 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit:HUNTER MESA UNI Unit Number:COC 55972X
Formation And Spacing:Code: RLNS , Formation: ROLLINS , Order: , Unit Acreage: , Drill Unit:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: , Unit Acreage: , Drill Unit:
Wellbore Completed
Completion Date:12/18/2003
Spud Date:8/30/2003Spud Date Is:ACTUAL
Measured TD:7729 ft.Measured PB depth:7736 ft.
True Vertical TD:7588 ft.True Vertical PB depth:0 ft.
Top PZ Location:Sec:12 Twp: Footage: 1310 FSL  1298 FEL
Bottom Hole Location:Sec:12 Twp: Footage: 1330 FSL  1310 FEL
Log Types:SCBL, PEX
Casing:String Type: SURF, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7729 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 1385, Top: 550 ft., Bottom: 7729 ft., Determination Method: CBL
Casing:String Type: 1ST, Hole Size: 12.25 in., Size: 830 in., Top: 0 ft., Depth: 830 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 450, Top: 0 ft., Bottom: 830 ft., Determination Method: CALC
FormationInterval TopLog BottomCoredDSTs
WASATCH0 ft.4342 ft.NN
WILLIAMS FORK4343 ft.7403 ft.NN
ROLLINS7404 ft.7729 ft.NN

Formation RLNS                     Formation Classification:  GW                     Status:  PR - 11/16/2003                Interval Top: 7448 ft.    Interval Bottom: 7456 ft.

 Completed Information for Formation ROLLINS
1st Production Date:N/AChoke Size:0.375 in.
Formation Name:ROLLINSCommingled:No
Production Method:FLOWING
Open Hole Completion:No
Formation Treatment
Treatment Date:12/18/2003
Treatment Summary:STAGE 1: ACID BALLOUT, 7448-7456, 16-0.340" SHOTS, 1817 BBLS OF SLICKWATER, 75,000# 20-40 SAND
Tubing Size:Tubing Setting Depth:
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:11/16/2003Test Method:FLOWING
Hours Tested:24Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 0
BBLS_OIL 1
BTU_GAS 1170
CALC_BBLS_H2O 0
CALC_BBLS_OIL 1
CALC_GOR 19
CALC_MCF_GAS 19
CASING_PRESS 550
MCF_GAS 19
Perforation Data:
Interval Top:7448 ft.# Of Holes:16
Interval Bottom:7456 ft.Hole Size:

Formation WMFK                     Formation Classification:  GW                     Status:  PR - 11/16/2003                Interval Top: 5342 ft.    Interval Bottom: 7274 ft.

 Completed Information for Formation WILLIAMS FORK
1st Production Date:N/AChoke Size:0.375 in.
Formation Name:WILLIAMS FORKCommingled:No
Production Method:FLOWING
Open Hole Completion:No
Formation Treatment
Treatment Date:12/18/2003
Treatment Summary:SEE OGCC COMMENTS
Tubing Size:2.375 in.Tubing Setting Depth:6750 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:11/16/2003Test Method:FLOWING
Hours Tested:24Gas Type:
Gas Disposal:
Test TypeMeasure
BBLS_H2O 0
BBLS_OIL 1
BTU_GAS 1170
CALC_BBLS_H2O 0
CALC_BBLS_OIL 1
CALC_GOR 1834
CALC_MCF_GAS 1834
CASING_PRESS 550
MCF_GAS 1834
Perforation Data:
Interval Top:5342 ft.# Of Holes:108
Interval Bottom:7274 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)2
Total Gas Produced (MCF)9719
GOR4859500
GOR DeterminationMCFE
Average BOE per Day4.597
Average MCFE per Day26.660

 Federal Financial Assurance  i Y

 Tribal Well  i No
