COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-07624		Well Classification: GW Status: PR - 10/5/2000
Well Name/No:BORUCH #GM 44-11
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:TEP ROCKY MOUNTAIN LLC - 96850
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:
Facility Status:PRStatus Date10/5/2000
FacilityID:258180LocationID:334727
Municipality/County:PARACHUTE / GARFIELD #045Location:SESE 11 7S96W 6
Field:GRAND VALLEY - #31290Elevation:5298 ft.
Basin:PICEANCE BASIN
Planned Location:523FSL  684 FELLat/Long: 39.446129 / -108.070385Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 39.446242 / -108.070562Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 8/24/2000             Measured TD: 6028 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 8/24/2000
Wellbore Permit
Permit #:001064 Expiration Date:10/4/2001
Proposed Depth/Form:6200 ft.
Surface Mineral Owner Same:Yes
Mineral Owner:FEESurface Owner:FEE
Unit: Unit Number:
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: 510-1 , Unit Acreage: , Drill Unit:
Wellbore Completed
Completion Date:2/3/2001
Spud Date:12/26/2000Spud Date Is:ACTUAL
Measured TD:6028 ft.Measured PB depth:
True Vertical TD:True Vertical PB depth:
Log Types:DUAL INDUCTION SPECTRAL DENSITY DUAL SPACED NEUTRON
Casing:String Type: SURF, Hole Size: 13.5 in., Size: 9.625 in., Top: , Depth: 300 ft., Weight: 32.3 , Citings Type: ACTUAL
Cement:Sacks: 180, Top: 0 ft., Bottom: 300 ft., Determination Method:
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: , Depth: 6017 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 775, Top: 1950 ft., Bottom: 6017 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WASATCH G1356 ft.NN
FORT UNION1652 ft.NN
CAMEO COAL5552 ft.NN
ROLLINS6016 ft.NN

Formation WFCM                     Formation Classification:  GW                     Status:  PR - 8/24/2000                 Interval Top: 4310 ft.    Interval Bottom: 5897 ft.

 Completed Information for Formation WILLIAMS FORK - CAMEO
1st Production Date:N/AChoke Size:
Formation Name:WILLIAMS FORK - CAMEOCommingled:No
Production Method:FLOWING
Open Hole Completion:No
Formation Treatment
Treatment Date:2/3/2001
Treatment Summary:
Tubing Size:2.375 in.Tubing Setting Depth:5454 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:2/13/2001Test Method:
Hours Tested:24Gas Type:
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 0
BBLS_OIL 0
CALC_BBLS_H2O 0
CALC_BBLS_OIL 0
CALC_MCF_GAS 1276
CASING_PRESS 1339
MCF_GAS 1276
TUBING_PRESS 1229
Perforation Data:
Interval Top:4310 ft.# Of Holes:64
Interval Bottom:5897 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)12
Total Gas Produced (MCF)7607
GOR633916
GOR DeterminationMCFE
Average BOE per Day3.630
Average MCFE per Day21.037

 Federal Financial Assurance  i

 Tribal Well  i No
