COGIS - WELL SCOUT CARD
Click image to view related facilities. Related  Click image to view inspection information. InspClick image to view MIT information. MITClick image to access interactive map at well/facility location. GISClick image to view imaged documents for this well/facility. DocClick image to view imaged documents for this well/facility. COAClick image to view wellbore completion diagram. WellboreClick image to search for orders within this facility's section. OrdersClick image to view bradenhead scoutcard data. Bradenhead
 Surface Location
 API# 05-045-07470		Well Classification: GW Status: PR - 3/26/2004
Well Name/No:HMU FEDERAL #18-15 (N18)
(Click Well Name for Production Data)		Click Here for Transporter Gatherer Info
Operator:QB ENERGY OPERATING LLC - 10844
(Click Operator Name for Company Detail Report)		Federal Or State Lease #:C56258
Facility Status:PRStatus Date3/26/2004
FacilityID:256551LocationID:334933
County:GARFIELD #045Location:SWSW 18 7S92W 6
Field:MAMM CREEK - #52500Elevation:6221 ft.
Basin:PICEANCE BASIN
Planned Location:1298FSL  653 FWLLat/Long: 39.442451 / -107.712154Lat/Long Source: Calculated From Footages
As Drilled Location:Footages Not AvailableLat/Long: 39.442540 / -107.712030Lat/Long Source: Field Measured
 Wellbore And Formation Details -- select either a wellbore Or formation to expand.


Wellbore #00             Wellbore Classification: GW             Status: PR - 3/26/2004             Measured TD: 7422 ft.    Vertical TD: 7422 ft.

 Wellbore Data for Original WellboreWellbore Classification: GW        PR - 3/26/2004
Wellbore Permit
Permit #:010111 Expiration Date:1/17/2002
Proposed Top PZ Location:Sec: Twp: Footage: 751 FSL  1965 FWL
Bottom Hole Location:Sec: Twp: Footage: 660 FSL  2197 FWL
Proposed Depth/Form:7150 ft.
Surface Mineral Owner Same:No
Mineral Owner:FEDERALSurface Owner:FEE
Unit:HUNTER MESA UNI Unit Number:55972X
Formation And Spacing:Code: WMFK , Formation: WILLIAMS FORK , Order: , Unit Acreage: , Drill Unit: U
Casing:String Type: CONDUCTOR, Hole Size: 20 in., Size: 16 in., Top: , Depth: 60 ft., Weight: , Citings Type: PLANNED
Cement:Sacks: 0, Top: 0 ft., Bottom: 60 ft.
Wellbore Completed
Completion Date:1/25/2002
Spud Date:6/28/2001Spud Date Is:ACTUAL
Measured TD:7422 ft.Measured PB depth:7422 ft.
True Vertical TD:7422 ft.True Vertical PB depth:
Top PZ Location:Sec: Twp: Footage: 789 FSL  1984 FEL
Bottom Hole Location:Sec: Twp: Footage: 678 FSL  1834 FEL
Log Types:PEX/GR/CNL/CBL/CCL/RST/AI
Casing:String Type: SURF, Hole Size: 12.25 in., Size: 8.625 in., Top: 0 ft., Depth: 763 ft., Weight: 24 , Citings Type: ACTUAL
Cement:Sacks: 360, Top: 0 ft., Bottom: 763 ft., Determination Method: CALC
Casing:String Type: 1ST, Hole Size: 7.875 in., Size: 4.5 in., Top: 0 ft., Depth: 7497 ft., Weight: 11.6 , Citings Type: ACTUAL
Cement:Sacks: 1130, Top: 2000 ft., Bottom: 7496 ft., Determination Method: CBL
FormationInterval TopLog BottomCoredDSTs
WILLIAMS FORK4214 ft.NN

Formation WMFK                     Formation Classification:  GW                     Status:  PR - 3/26/2004                 Interval Top: 5118 ft.    Interval Bottom: 7358 ft.

 Completed Information for Formation WILLIAMS FORK
1st Production Date:10/25/2001Choke Size:0.375 in.
Formation Name:WILLIAMS FORKCommingled:No
Production Method:FLOWING
Open Hole Completion:No
Formation Treatment
Treatment Date:1/25/2002
Treatment Summary:STAGE 1: ACID BALLOUT, 6963'-7358", 0.34", 4640 BBL KCL SLICKWATER, 196,000# 20/40 SAND. STAGE 2: ACID BALLOUT, 5887'-6251', 18 HOLES, 0.34", 3869 BBL KCL SLICKWATER, 170,000# 20/40 SAND. STAGE 3: ACID BALLOUT, 5580'-5764',16 HOLES, 0.34", 4124 BBL KCL
Tubing Size:2.375 in.Tubing Setting Depth:5876 ft.
Tubing Packer Depth:Tubing Multiple Packer:
Open Hole Top:Open Hole Bottom:
Initial Test Data:
Test Date:10/29/2001Test Method:FLOWING
Hours Tested:24Gas Type:DRY
Gas Disposal:SOLD
Test TypeMeasure
BBLS_H2O 178
BBLS_OIL 10
BTU_GAS 1170
CALC_BBLS_H2O 178
CALC_BBLS_OIL 10
CALC_GOR 169
CALC_MCF_GAS 1693
CASING_PRESS 1260
MCF_GAS 1693
Perforation Data:
Interval Top:5118 ft.# Of Holes:80
Interval Bottom:7358 ft.Hole Size:
Primary Well Designation:
None      i
            All DesignationsDate
Reported PluggedN
Out Of Service RepurposedN
Out Of ServiceN
Inactive ExceptionN
Noticed InactiveN
Defined InactiveN
Low ProducingN

BOE/MCFE/GOR Calculations
Production for Previous 12 Months
October 2024 - September 2025i
Total Oil Produced (Barrels)0
Total Gas Produced (MCF)4238
GOR
GOR DeterminationMCFE
Average BOE per Day2.005
Average MCFE per Day11.605

 Federal Financial Assurance  i Y

 Tribal Well  i No
